Rixson 680 3/4" Offset Top Pivot
×
This image is for a similar product but it will differ in size, color and/or other attributes.
×
This product review video is for a similar product but it will differ in size, color and/or other attributes.
Price:
$
388.55 USD
In Stock Ready for Shipment
1. Select Finish____________________
Bright Brass (605/632) - Plated
Satin Brass (606/633) - Plated
Bright Bronze (611/637) - Plated
Satin Nickel (619) - Plated
Bright Nickel (618) - Plated
Coated Black (622/693) - Plated
Coated Aluminum (627/628) - Plated
Satin Bronze (612/639) - Plated
Oil Rubbed Bronze (613/640) - Plated
Bright Chrome (625/651) - Plated
Satin Chrome (626/652) - Plated
Bright Stainless (629) - Plated
Satin Stainless (630) - Plated
2. Select Handing__________________
LH (Left Hand)
RH (Right Hand)
LHR (Left Hand Reverse)
RHR (Right Hand Reverse)
Comments
(Optional)
ADD TO CART
In Stock (Minimums Apply
):
For quantities beyond the "In Stock" above, the item(s)
ships in 1 business day.
Additional Declarations -
This manufacturer has an order minimum of $85.00 - if your total is less than this amount, the lead time approximately 2-3 weeks before it would ship. Simply exceed this minimum order amount so that we can drop ship the material to your location.
Check Inventory
Request Quote
No Minimum
There is no minimum quantity required for this product for quantities up to the level listed below.
Minimum Order Levels Apply
You must order a total of $85.00 worth of product from Rixson to place an order.
Check Inventory Levels
Enter your email address and we will check with all available sources and get back to you with exact inventory levels and estimated shipping times.
Qty. Needed:
Request Quote
Enter the qty needed and we will generate a quote and save your order in our system.
You will not be charged and we will not fulfill the order.
Qty. Needed:
+ Add to My Wish List
1-844-809-3667
Sales
sales@absupply.net
Technical Support
tech@absupply.net
Product Description:
Rixson Pivots
680 3/4" Offset Top Pivot- Extra Length Pins Available in Extra Order
Templates
Product Brochure
A
pplication
◊ Side Jamb Mounted
◊ Frame Portion
◊ Handed
I
ntroduction
Pivot sets provide the best possible means of hanging a door. They are designed to work with the laws of physics to provide long-lasting performance and reliability.
The weight of the door is supported entirely by the bottom arm, which is directly connected to the pivot spindle. This hanging means provides several important advantages:
• Fasteners on the door and frame are in shear rather than tension (as with hinges) and are less likely to pull out overtime. This creates less stress on the frame assembly, prevents door sagging and allows the door to swing with less resistance from friction.
• A door supported in this manner relies on the strength of the floor to carry the weight, not the frame. This allows extremely heavy doors to be hung in an opening and allows door adjustment throughout the life of the building to compensate for settlement.
P
roduct Description & Features
• Used where no frame exists above door, or where it is not possible to anchor pivot into header of frame
• Non-ferrous base metal
• 3/4"(19mm) offset (measured from centerline of pivot to face of door)
• Side jamb portion can be surface mounted or mortised
T
echnical Information
Questions and Answers
Q: is this item available to ship immediatly?
A:
This item in indeed typically kept in stock.
