Hager 2941

Name: Hager 2941 Electrified Magnetic Lock with 600 lb. Holding Force - Aluminum
Brand: Hager
SKU: Hager 2941
Price: 251.53 USD

Hager 2941 Electrified Magnetic Lock with 600 lb. Holding Force - Aluminum

× This image is for a similar product but it will differ in size, color and/or other attributes.

Hager 2941 Electrified Magnetic Lock with 600 lb. Holding Force - Aluminum

Price: $251.53 USD

Comments (Optional)

ADD TO CART

In Stock (No Minimums):

Naples, FL Warehouse Qty: 1

For quantities beyond the "In Stock" above, the item(s) ships in 15 business days.

+ Add to My Wish List

1-844-809-3667

Sales

sales@absupply.net

Technical Support

tech@absupply.net

Product Description:

2941 Electrified Magnetic Lock with 600 lb. Holding Force - Aluminum

2941 Magnetic Lock
Use: For interior door traffic control where physical attack is not a concern
Designed for system integrators, distributors, installers, and building owners presently using low cost import or private label brand access control hardware
ANSI/BHMA A156.23 GRADE 1 Compliant
Easy to install
Provides superior, less obtrusive appearance compared to stainless steel epoxy sealed magnetic locks
Full monitoring standard
Quick mount assembly reduces installation time
Includes: Door and lock status outputs for remote monitoring and system application needs
Holding Force: 600 lbs (272 kg)
Lock:
- 9-7/8" (l) x 2" (h) x 1" (d)
- 250 (l) x 73(h) x 41 (d) mm
Armature:
- 7-5/16" (l) x 1-1/2" (h) x 1/2" (d)
- 186 (l) x 38 (h) x 13 (d) mm
Voltage:
- 12/24 VDC, field selectable
- 500 mA @ 12 VDC; 250 mA @ 24 VDC
Circutry/Wiring: PC board with voltage and current spike protection, instant release anti-residual magnetism circuit, terminal block for power input and status outputs
Lock Status: SPDT, 2 mA @ 30 VDC
Door Status: SPDT, 500 mA @ 30 VDC
Standard Features:
- Door status, lock status and bi-color LED
- Interlocking quick mount assembly
- Adjustable mounting bracket with choice of self-drilling and tapping mounting screws or machine screws
- Wire access chamber with terminal block
- Dual voltage 12/24 VDC
- Finish: Clear anodized aluminum
Case Quantity: 4
Sold per piece
Accessories:
- 2-679-0101 - Top Jamb Kit
- 2-679-0103 - Glass Armature Mounting Kit
- 2-679-0105 - Adjustable Angle Bracket
- 2-679-0106 - Angle Bracket (cut to fit 2941)
- 2-679-0107 - Stop Filler Plate (field cut for 2941)
- 2-679-0108 - Stop Filler Plate (field cut for 2941)
