Hager 2909

Name: Hager 2909 Modular Access Control Power Supply
Brand: Hager
SKU: Hager 2909
Price: 560.02 USD

Hager 2909 Modular Access Control Power Supply

× This image is for a similar product but it will differ in size, color and/or other attributes.

Price: $560.02 USD

Comments (Optional)

In Stock (No Minimums):

Naples, FL Warehouse Qty: 1

For quantities beyond the "In Stock" above, the item(s) ships in 15 business days.

Sales

Technical Support

Product Description:

2909 Modular Access Control Power Supply

2909 - Regulated modular access control power supply
Provides up to 2 amps of 12 or 24 volt DC power for all Hager Electrified Products
Filtering and output voltage regulation provide protection and ensure the longevity of all system components
Equipped with a high performance transformer and highly reliable electronic components
Fire alarm input that provides simultaneous release of all Fail Safe locks and door holders in case of emergency
Circuit breaker protected AC input voltage - secondary output is PTC protected
Field selectable output that provides 12 VDC or 24 VDC
LED status indicators to provide information regarding the AC input, DC output, and battery backup status
Separate PTC protected charging output
Optional dual 12 VDC or 24 VCD outputs
Standard California compliant manual release
Input:
- 115 VAC, 600 mA, 50/60 Hz (230 VAC optional)
Output:
- 12/24 VDC, 1 amp
Cabinet:
- 12" x 12" x 4", 18 GA
- 305 x 305 x 102 mm
Battery Charger:
- 13.5/27 VDC, 500 mA
Accessories:
- 2-679-0661 - 5 Amp hour battery backup
- 2-679-0662 - 12 VDC output regulator module
- 2-679-0664 - Universal relay module
