The ND80EL, ND80EU, ND96EL, ND96EU, ND12EL, ND12EU electrified locks manufactured prior to March 14, 2016 do not have the ability to add an RX option in the field. A new lock chassis or complete lock would need to be purchased.
The ND80, ND12, ND96 and ND10 non electrified mechanical locks always have to be ordered as a complete lock with N123-062 (RX). If an N123-062 (RX) is required on an existing non electrified lock a new lock chassis would have to be purchased to field convert (Example: ND80 LD LLL 626 LLL LLL N123-062, lever chassis).
On ND locks manufactured prior to January 30, 2017, the lever, spring cage and tailpiece needed to be replaced with the SFIC lever, SFIC spring cage and the SFIC driver .
