McKinney MK67003 MK40A Series Concealed Hinge - Matte Black
×
This image is for a similar product but it will differ in size, color and/or other attributes.
×
This product review video is for a similar product but it will differ in size, color and/or other attributes.
Price:
$
38.64 USD
In Stock Ready for Shipment
Comments
(Optional)
ADD TO CART
Quick Ship -
up to 10 units available to ship in 10 business days
For quantities beyond the "In Stock" above, the item(s)
ships within 14 business days.
Check Inventory
Request Quote
No Minimum
There is no minimum quantity required for this product for quantities up to the level listed below.
Minimum Order Levels Apply
This item has minimum order levels that need to be met.
Check Inventory Levels
Enter your email address and we will check with all available sources and get back to you with exact inventory levels and estimated shipping times.
Qty. Needed:
Request Quote
Enter the qty needed and we will generate a quote and save your order in our system.
You will not be charged and we will not fulfill the order.
Qty. Needed:
+ Add to My Wish List
1-844-809-3667
Sales
sales@absupply.net
Technical Support
tech@absupply.net
Product Description:
McKinney MK67003 MK40A Series Concealed Hinge - Matte Black
Refined and minimal, the McKinney Concealed Hinges feature 3-Dimension adjustability for easy installation and door alteration.The snap-on covers conceal screws for a clean aesthetic.
Concealed Hinge
Model number: MK40A (Covers included)
Base material: Zinc alloy
Finish: Matte Black
Overall Size: 4-1/2" x 7/8"
Hinge length: 115 mm (4-1/2")
Hinge width: 23 mm (7/8")
Non-handed
Opening angle: 180°
3-Dimensional adjustability: Height +/- 1.5 mm; side +/- 1.5 mm; and depth +/- 1 mm
For wood or hollow metal doors with wood or metal frames
Door thickness minimum: 1-1/4"
Sold as each. When you order one you will receive one hinge. Price is for one hinge.
Hinge Capacity (for door thickness minimum: 1-1/4"):
Number of Hinges
Door Width
32"
36"
42"
48"
2
92 lbs
88 lbs
72 lbs
66 lbs
3
105 lbs
99 lbs
81 lbs
74 lbs
4
116 lbs
110 lbs
86 lbs
79 lbs
Product Brochure
CutSheet
Installation Instruction
MK40A 3D Adjustment Video
