Q: is there a kit to retro-fit a Kawneer rim panic with an alarm ?
A: Are you looking for an audible sound to aim it at the door is open or are you looking to report back to a monitoring station at the door is opened and can you tell me what type of door and frame do you have?
Q: Do you sale replaement parts the the Kawneer 1786 rim exit? I have a device thats misisng the parts that allow the unit to be unlocked
A: yes indeed - we have available all the service parts Kawneer makes available to market with a PArts Drawing available here:
Click Here
Q: Do you offer replacement parts for the Kawneer 1786 rim eixt? I have a customer that the Rim cylinder spins the two little parts the engage the bar to pull the bolt back are missing. I can send phot'os once you email me.
A: Yes we indeed do and the part you require to mitigate this problem is the Kawneer 133633 1786 EXIT DEVICE LATCH MECHANISM PACKAGE and is see in the manufacturers Parts List as seen here on page A18/24:
Download File
Q: Does the Kawneer 1786 rim exit device use a Rim Cylinder?
A: If referring to cylinder dogging or the Kawneer lever escutcheon trim it would be a mortise cylinder. If referring to adding simple exterior cylinder control it would be a rim cylinder.
Q: is just the crash bar available
A: The replacement touch pad assembly is indeed available.
Please see the manufacturer's parts drawing as seen here:
Download File
Please confirm that part number one is the part that would meet your requirements
Q: Can the Kawneer 1686 Concealed Rod Exit Device and the 1786 Rim Exit Device installed for exterior condtions. 100% exposeure to the elements. My location is Northern Virginia, outside Washington DC. Do you have any recommendations for an alternate product? Any idea how long the device will last prior to replacement.
A: I can certainly be installed in an exterior application however you have material in there that's made of steel so like anything exposed to the elements, it will eventually fail.
I see hardware installed an exterior devices all the time and they doesn't seem to be a failure issue as in immediate and obvious - could be 6 months could be 6 years - I suggest keep a device on hand ready to install when operation becomes intermittent. The issue if the device fails and emergency egress cannot be provided at that opening.
In this sort of scenario you may not have any options because your doors already prepped for this precise hardware. Again - I would simply keep in stock a replacement device ready to go when it just continues proper operation as a result of the 100% exposure to the elements.
Q: Can the 1786 rim exit device replace a 1686 concealed rod exit device on a door?
A: I would say you would certainly be able to remove the concealed vertical rod exit device and install a rim device in its place however the function holes in mounting holes and all of the other additional holes required for the concealed vertical rod exit device, of course, will possibly be requiring attention and I would imagine that they installed a concealed vertical rod in a pair of doors and to install a rim device on a pair of doors without adding a mullion would not be possible - please tell me more about your application.
Q: can you add a outside lever handle to a 1786 Rim Panic
A: Yes you can. The Kawneer 133648-17 1786 Lever Handle as seen here would be the proper sort of exterior lever trim for your 1786 series exit device:
Click Here
Q: is there a lock for this device that wont unlock totally. so you have to turn key all the way back to remove and door stays locked
A: I would use the Kawneer 133648-17 1786 Lever Handle for A Standard Door 190/350/500 Aa250/425, 350/500 Doors, Clear Aluminum as seen here:
Click Here
which would be classified most commonly as a Classroom function. The cylinder locks and unlocks the lever trim and the inside is always free as it is a panic.
Q: Can the 1786 be dogged down using the rim cylinder on exterior?
A: Exterior dogging is not possible on the
Kawneer 1786-17 Rim Exit Device - 3' Door - Clear Finish
and can only be accomplished from the interior or egress side.
Q: can a MLR option be added to the rim device
A: Yes most certainly it can be - the item to a Id would be the part number Kawneer 133649 1686/1786 Manual Exit Part To MEL Motor as seen here:
Click Here
However be mindful that you will also require the power supply which is the part number Kawneer 050419 NP1 POWER SUPPLY APPROVED FOR USE WITH KAWNEER 1686 MEL & 1786 MEL EXIT DEVICES - OPERATES UP TO 2 DEVICES as seen here:
Click Here
Q: can i convert kawneer 1786 hex key dogging to cylnder dogging
A: Unfortunately Kawneer does not offer a cylinder dogging kit upgrade from hex key dogging.
Q: Is there a kit or part to just replaced a stripped out dogging mechanism?
A: How about the Kawneer 133636 1686/1786 Dogging Device Package
as seen here:
Click Here
