Kawneer 133621-40

The Kawneer 1686 Concealed Rod exit device is an exclusive to Kawneer customers. This exit device is UL Listed, is Hurricane Impact tested and Florida Product Approved. This device has the feature of rod adjustment without panel removal. Depression of the touchbar on the interior retracts the concealed rods from the transom bar and the threshold, allowing egress from the building. Upon closing, the top rod is released and frees the bottom rod to engage the threshold. The door is now relocked. A quick single point dogging feature in the housing deactivates the device and permits unrestricted traffic flow. Vertical rods and latch mechanisms are concealed in the vertical door stile. A 1-5/32" diameter mortised 5-pin cylinder with trim is required.

• Application: Designed for use on single or pairs of doors. It is suited for medium and high traffic areas. Available on 190, 350, and 500 Standard Entrances, 350/500 IR, 350/500 Heavy WallTM, 350/500 Heavy WallTM IR Entrances, and AATM 250/425 Thermal Entrances.
• Dimensions: Center line of touchbar to bottom of door 40" (1,016); height 3-3/16" (81); Projection 2-3/4" (70); Projection when dogged 1-13/16" (46).
• Concealed Exit Device for A 3-0 Door LH/RHR
• Price includes: Exit device and loose parts bag
• Finish: Dark Bronze
• 12" Bolt Extension in clear aluminum or dark bronze finish is available here: Kawneer 133285-17, Kawneer 133285-40
• NOTE: We also sell this product in different variant Kawneer 133621-17 in Clear Aluminum Finish.
• Packing & Sold as: Each.
• Note: Unit of measure is EA. When you buy a quantity of 1 you will get one piece. Price is for one piece.
