BEA 10TD433HH1

Name: BEA 10TD433HH1 Digital Transmitter 433 MHz with One Button
Brand: BEA
SKU: BEA 10TD433HH1
Price: 49.86 USD

BEA 10TD433HH1 Digital Transmitter 433 MHz with One Button

× This image is for a similar product but it will differ in size, color and/or other attributes.

BEA 10TD433HH1 Digital Transmitter 433 MHz with One Button

Price: $49.86 USD

Comments (Optional)

ADD TO CART

In Stock (No Minimums):

Naples, FL Warehouse Qty: 3

In Stock (Minimums Apply):

For quantities beyond the "In Stock" above, the item(s) ships in 2 business days.

BEA has a minimum order requirement. Orders smaller than the required minimum have a longer lead time as we need to consolidate onto a "stock" order. If you need a faster lead time, simply exceed the minimum order amount.

+ Add to My Wish List

1-844-809-3667

Sales

[email protected]

Technical Support

[email protected]

Product Description:


Digital Transmitter 433 MHz with One Button

Digital Transmitter 433 MHz with One Button controls one 10RD433 Receiver. The 433MHz Series Transmitters and Receiver are ideal for the wireless activation and/or sequencing of automatic doors. The Transmitters are available in hand-held styles and they transmit a unique rolling code each time the transmitter is activated (thus providing a secure door opening signal). Since receivers can be individually programmed, multiple receivers can be programmed differently thus allowing for sequencing in multiple applications. Upon activation (pushplate / transmitter), all receivers will acquire the signal at the same time; however, each receiver will respond according to their programming. Those receivers programmed with NO DELAY will active immediately upon receiving the transmitter signal. Those receivers programmed with a DELAY will activate at the end of their pre-determined time delay set by the potentiometer. The use of multiple receivers will allow for the uninterrupted pace or hands free operations through a pair of doors upon initial activation.	Technical Data Instructions Product Catalog

(Click to Enlarge)
(Click to Enlarge)
(Click to Enlarge)
(Click to Enlarge)
(Click to Enlarge)
(Click to Enlarge)
(Click to Enlarge)

Video Detail Page

Questions and Answers

Q: Good afternoon, I had a question in regard to product BEA 10TD433HH1 my building currently has this system installed and were looking to purchase more transmitters, just was curious since Ive opened the fob up and dont see any dipswitches, do these transmitters automatically sync up with our current unit or how do they need to be programmed i dont see a video on the website showing this info

A: Which receiver are you pairing the BEA 10TD433HH1 Digital Transmitter 433 MHz with One Button to?

Q: The receiver being used is BEA 10RD433

A: All of the programming for the 10TD433HH1 is done on the 10RD433 and its installation instructions can be seen here:

Download File

would it help if I created a video on "how" to pair these?
