Knape BIF-50A-4D-4
Knape BIF-50A-4D-4
Knape & Vogt BIF-50A-4D-4 Bi-Fold 50 Lbs. Panels With Aluminum Track For 4 Doors For 48" Opening
×
This image is for a similar product but it will differ in size, color and/or other attributes.
×
This product review video is for a similar product but it will differ in size, color and/or other attributes.
Price:
$
62.88 USD
In Stock Ready for Shipment
Comments
(Optional)
ADD TO CART
This item is not in stock and typically ships in 20 business days. K & V has a minimum order and case quantity requirement. Orders for material not on hand have a longer lead time as we need to consolidate onto a "stock" order. If you need a faster lead time, simply exceed the minimum order amount.
Additional Declarations -
If inventory is in stock and available to ship immediately, the quantity will be listed above under
Immediate
above. Otherwise the Standard Lead Time applies.
Check Inventory
Request Quote
No Minimum
There is no minimum quantity required for this product for quantities up to the level listed below.
Minimum Order Levels Apply
This item has minimum order levels that need to be met.
Check Inventory Levels
Enter your email address and we will check with all available sources and get back to you with exact inventory levels and estimated shipping times.
Qty. Needed:
Request Quote
Enter the qty needed and we will generate a quote and save your order in our system.
You will not be charged and we will not fulfill the order.
Qty. Needed:
+ Add to My Wish List
1-844-809-3667
Sales
sales@absupply.net
Technical Support
tech@absupply.net
Product Description:
BIF-50A-4D-4 Bi-Fold 50 Lbs. Panels With Aluminum Track For 4 Doors For 48" Opening
SLIDING
DOOR HARDWARE
BI-FOLD
BY-PASS
POCKET/FRAME
WALL-MOUNT
The BIF-50A (aluminum track) series hardware for medium to light-weight two or four bi-fold doors used for residential interior closets, pantries.
Packaged Set of a 47" Aluminum Box Track for 4 doors 50 lbs. each with thickness of 1-3/8" to 1-3/4" with door hardware components included (see table below).
Door Panel Configuration:
4 x 12" doors
Track Length:
47"
Door Panels:
4
Note:
for Complete Package Sets order a package set that has your required door opening length. The package set includes the noted track length and hardware for installation, along with installation instructions (see table below for options).
Packaged sets are for 1-3/8" to 1-3/4" thick doors. For 3/4" to 1-1/8" door thicknesses, order individual tracks and part bags
PB-BIF-50-2ND
for two door applications and
PB-BIF-50-4ND
for four door applications.
Instructions
Track Types
Door Weight Table
Hardware Components for 50A Series Bi-Fold Door Configuration:
BIF-50A-2D-3
BIF-50A-4D-4
BIF-50A-4D-6
BIF-50A-4D-8
Aluminum Track-1601
35"
47"
71"
96"
Snugger-BK-0815
1
2
2
2
Jamb Bracket-8643
1
2
2
2
Wrench-8665
1
1
1
1
Door Guide Plate-3179
1
2
2
2
Adjustment Screw Assembly-1500-BPASA
1
2
2
2
Pivot Pin Plate Assembly-8582
1
2
2
2
Quick Release Top Mount Plate-BK-1800-DBA
1
2
2
2
Wood Door Knob-PB-1558-R
1
2
2
2
Aligner (Bright Zinc)-PB-1559-ZN
-
2
2
2
4-Wheel Ball Bearing Carrier-BK-1606-QR
1
2
2
2
Heavy-duty Pivot Assembly-3313
1
2
2
2
Hinge With Screws-BK-8220-ZC
3
6
6
6
Screws
Yes
Yes
Yes
Yes
Note: Packaged sets are for 1-3/8" to 1-3/4" thick doors.
For 3/4" to 1-1/8" door thicknesses, order individual tracks and part bags PB-BIF-50-2ND for two door applications and PB-BIF-50-4ND for four door applications.
Hardware Components for 50S Series Bi-Fold Door Configuration:
BIF-50S-2D-3
BIF-50S-4D-4
BIF-50S-4D-6
BIF-50S-4D-8
Steel Track-1599
35"
47"
71"
95"
Snugger-BK-0815
1
2
2
2
Jamb Bracket-8643
1
2
2
2
Wrench-8665
1
1
1
1
Door Guide Plate-3179
1
2
2
2
Adjustment Screw Assembly-1500-BPASA
1
2
2
2
Pivot Pin Plate Assembly-8582
1
2
2
2
Quick Release Top Mount Plate-BK-1800-DBA
1
2
2
2
Wood Door Knob-PB-1558-R
1
2
2
2
Aligner (Bright Zinc)-PB-1559-ZN
-
2
2
2
4-Wheel Ball Bearing Carrier-BK-1606-QR
1
2
2
2
Heavy-duty Pivot Assembly-3313
1
2
2
2
Hinge With Screws-BK-8220-ZC
3
6
6
6
Screws
Yes
Yes
Yes
Yes
Note: Packaged sets are for 1-3/8" to 1-3/4" thick doors.
For 3/4" to 1-1/8" door thicknesses, order individual tracks and part bags PB-BIF-50-2ND for two door applications and PB-BIF -50-4ND for four door applications.
Click Image to Enlarge
Accessory Options:
PB1064-26DA
Bi-Fold door lock, nickel, keyed alike
PB1064-US26D
Bi-Fold door lock, nickel, keyed different
PB1064-US3
Bi-Fold door lock, brass, keyed different
PB1064-US3A
Bi-Fold door lock, brass, keyed alike
Note:
Bi-Folding Sliding Door Hardware can be purchased by ordering the Tracks and Part Bags separately. Choose the correct track length (see Track Options table below). Most tracks may be cut-to-size in the field. Then choose the correct part bag based on the number of panel doors. Installation instructions are included in each part bag:
Hardware Components for Part Bags (BIF-50S/A):
PB-BIF-50-2
PB-BIF-50-4
PB-BIF-50-2ND
PB-BIF-50-4ND
Door Thickness:
1-3/8" to 1-3/4" doors
3/4" to 1-1/8" Narrow doors
Snugger-BK-0815
1
2
1
2
Jamb Bracket-8643
1
2
1
2
Wrench-8665
1
1
1
1
Door Guide Plate-3179
1
2
-
-
Door Guide Plate-3179-ZNND
-
-
1
2
Adjustment Screw Assembly-1500-BPASA
1
2
-
-
Pivot Pin Plate Assembly-8582
1
2
1
2
Quick Release Top Mount Plate-BK-1800-DBA
1
2
-
-
Top Mount Plate-1407-TMND
-
-
1
2
Wood Door Knob-PB-1558-R
1
2
1
2
Aligner (Bright Zinc)-PB-1559-ZN
-
2
-
2
4-Wheel Ball Bearing Carrier-BK-1606-QR
1
2
-
-
4-Wheel Carrier-1572-N
-
-
1
2
Heavy-duty Pivot Assembly-3313
1
2
1
2
Hinge With Screws-BK-8220-ZC
3
6
-
-
Hinge-8210
-
-
3
6
Screws
Yes
Yes
Yes
Yes
Note:
PB-1618 Top And Bottom Pivot Assemblies
includes pivot pin plate (8582); heavy-duty pivot assembly (3313); door guide plate (3179); adjusting screw (1500-BPASA); jamb bracket (8643)
Steel Track Options:
BK-1599-Z35
35" Steel Track For 2 Panels
BK-1599-Z47
47" Steel Track For 4 Panels
BK-1599-Z55
55" Steel Track For 4 Panels
BK-1599-Z59
59" Steel Track For 4 Panels
BK-1599-Z63
63" Steel Track For 4 Panels
BK-1599-Z71
71" Steel Track For 4 Panels
BK-1599-Z95
95" Steel Track For 4 Panels
BK-1599-Z119
119" Steel Track For 4 Panels
BK-1599-Z143
143" Steel Track For 4 Panels
Aluminum Track Options:
BK-1601-35
35" Aluminum Track For 2 Panels
BK-1601-47
47" Aluminum Track For 4 Panels
BK-1601-55
55" Aluminum Track For 4 Panels
BK-1601-59
59" Aluminum Track For 4 Panels
BK-1601-71
71" Aluminum Track For 4 Panels
BK-1601-96
96" Aluminum Track For 4 Panels
BK-1601-120
120" Aluminum Track For 4 Panels
BK-1601-144
144" Aluminum Track For 4 Panels
BK-1601-192
192" Aluminum Track For 4 Panels
