Sargent 8G05 0B

• For Doors – 1-3/8” (35mm) thick door adjustable to 1 3/4” (44mm) standard
• Backset – 2-3/4” (70mm) standard, optional 3 3/4” (95mm), optional 5” (127mm) backset available
• Aligning Tube – Machined brass from solid bar stock
• Front – Wrought brass, bronze or stainless steel 2-1/4” x 1-1/8” (57mm x 29mm) self-adjusting for fl at to 1/8” (3mm) bevel
• Strike – Wrought brass, bronze or stainless steel, 4 7/8” ANSI 808 curved lip strike standard, 800 curved lip strike available
• Hand – Universal, not handed
• Latch – Stainless steel bolt 1/2” (13mm) throw • Cylinder – Brass, 6 pin, LA keyway standard
• Door Prep – ANSI151.2 (US161) • Minimum Stile – 4-1/2” (114mm)

• Details

Office/Entry Function

• Key outside retracts latch always
• Button inside can be pushed-in & turned only
• Button inside pushed-in & turned, locks outside knob until released manually
• Knob inside always retracts latchbolt
• Deadlocking latch
• ANSI F81

• Versatile design to satisfy door requirements, making installation easy for new construction, as well as, retrofits and renovations
• Accurate alignment, smooth operation and reversibility of the lock without disassembly of knob and cylinder
• Design accommodates common door preps and satisfies all door handing
• Maintain and expand master keying systems’ versatility for multiple levels of security
• Complements and blends with trim designs of other SARGENT locks for unified appearance.
