Norton 6930 RF1
Norton 6930 RF1
Norton 6930 RF1 Door Opener With Push Side Double Lever Arm And Radio Frequency
×
This image is for a similar product but it will differ in size, color and/or other attributes.
×
This product review video is for a similar product but it will differ in size, color and/or other attributes.
Price:
$
7,599.60 USD
In Stock Ready for Shipment
1. Select Finish
Aluminum - 689
Dark Bronze - 690
2. Select Handing
LH Left Hand
RH Right Hand
LHR Left Hand Reverse
RHR Right Hand Reverse
Comments
(Optional)
ADD TO CART
In Stock (Minimums Apply
):
For quantities beyond the "In Stock" above, the item(s)
ships in 1 business day.
Check Inventory
Request Quote
No Minimum
There is no minimum quantity required for this product for quantities up to the level listed below.
Minimum Order Levels Apply
You must order a total of $100.00 worth of product from Norton to place an order.
Check Inventory Levels
Enter your email address and we will check with all available sources and get back to you with exact inventory levels and estimated shipping times.
Qty. Needed:
Request Quote
Enter the qty needed and we will generate a quote and save your order in our system.
You will not be charged and we will not fulfill the order.
Qty. Needed:
+ Add to My Wish List
1-844-809-3667
Sales
sales@absupply.net
Technical Support
tech@absupply.net
Product Description:
6930 RF1 Door Opener With Push Side Double Lever Arm And Radio Frequency
Frame reveals 2-3/4" to 6-7/8" (70 to 175mm)
Door Opening Up to 180°
An auxiliary stop is suggested where severe conditions exist
Adjustable Size 1-6
Left or right hand
Drop plate for low ceiling applications
Push-side or pull-side applications
Power Assist selector switch
Push and Go selector switch
Open/close obstruction detection
Motor startup delay adjustment
Vestibule function delay adjustment (For sequencing two or more units)
Door hold open delay adjustment
Single Pole Double Throw (SPDT) relay output
SPDT relay output time adjustment
SPDT alarm output
Blow open function for smoke ventilation
Infinite hold open function
Presence detector input
24 VDC @ .5A output
Selector mode switch (3 position)
- OFF – Disables signal inputs except blow open. Unit still powered.
- ON – Activates signal inputs for normal use
- HOLD OPEN – Activates the unit to the hold open position indefinitely
Template
Technical
Specifications
Applications
Certifications
Meets requirements for UL10C and UBC 7.2 for positive pressure
2-year warranty (refer to current price list, terms and conditions)
Americans with Disabilities Act (ADA)
ANSI/BHMA A156.19 certified
UL Listing: Listed for use on fire and smoke barrier door assemblies when the 120VAC (60Hz) power input is supplied through the normally closed alarm contacts of a compatible U.L. listed alarm system or alarm panel
C-UL US listed for use on fire and smoke barrier doors
California State Fire Marshal: 3550-944:109
Electrical Data
Power input 120 VAC, 60 Hz (+10%, -15%)
Current draw 1.5A
Auxiliary output 24 VDC @ .5A
SPDT relay output for controlling electric strikes or electric locks not to exceed 1 amp @ 30 VDC
Handing Chart
