Kawneer 050719

copy to clipboard

Kawneer 050719 Offset Arm Package for Single Acting Door

enlarge
enlarge
× This image is for a similar product but it will differ in size, color and/or other attributes.
Kawneer 050719 Offset Arm Package for Single Acting Door
Video Review Kawneer 050719 Offset Arm Package for Single Acting Door
More from Kawneer
Price: $209.71 USD
Ships From
Comments (Optional)
In Stock (No Minimums):
Naples, FL Warehouse Qty: 2
In Stock (Minimums Apply):
For quantities beyond the "In Stock" above, the item(s) ships in 15 business days.
Additional Declarations - This manufacturer has an order minimum of $85.00 - if your total is less than this amount, the lead time approximately 2-3 weeks before it would ship. Simply exceed this minimum order amount so that we can drop ship the material to your location.

1-844-809-3667

Sales
Technical Support
Product Description:
Kawneer Offset Arm Package for Single Acting Door
  • Exit Device Service Part
  • Offset arm for the Husky 2 concealed overhead door closer
  • The concealed top arm and track are adaptable to most Kawneer entrance doors
  • This door control system is suited for areas of medium and high traffic volume
  • Door control is achieved through the concealed top arm which is attached to the closer shaft and connected to a guide shoe sliding in a stainless steel track concealed in the top rail of the door. An aluminum block with a rubber cushion mounted in the guide track provides a shock-absorbing stop at approximately 105 degrees
  • This application of the concealed closer offers the same aesthetic and functional advantages of the double acting closer along with the superior weathering of an offset hung door and the over-swing control provided by a built-in door stop
  • The door, hung on either butt hinges, continuous hinge or offset pivots, makes continuous contact with weatherstripping at top and side jambs
  • Arm package includes flat head socket screws
  • Duty: Light Duty
  • Spring Size: Medium Duty (MD)
  • Spindle Size: 5MM Extended Spindle
  • Track Dimensions:
    • Length: 12-1/4"
    • Width:1-7/16"
    • Height: 5/16"
Customer Images:
Questions and Answers
There are currently no questions or answers.
(Required, used to email you once question is answered.)
