Q: install instructions for replacing dogging pin
A: 1. Remove the arm assembly from the door by removing 3 set screws
2. Remove the set screw that holds the dogging assembly in the body assembly
3. Replace all
Is there a follow up question that we can perhaps attempt to answer? We take pride deep in our technical expertise, as we know it separates us from our competition, so don't hesitate to ask.
Please reply to this email or contact our sales department here:
Click Here
if we can assist you by answering further questions or with entering this order and please let us know if there is anything else we can help with.
Q: What is the proper cylinder mounting pad and cylinder type required to make this accessible from the exterior via a key?
A: For the Jackson 31-1085 Concealed Vertical Rod Device, the correct Cylinder Mounting Pad is the Jackson 30-821J as seen here in 628 aluminum finish:
https://absupply.net/jackson-30-821j628-mortise-cylinder-mounting-pad-satin-aluminum.aspx
and the correct cylinder is a 1" long mortise cylinder with an "Adams Rite" cam as seen here:
Click Here
Is there a follow up question that we can perhaps attempt to answer? We take deep pride in our technical expertise, as we know it separates us from our competition, so don't hesitate to ask.
Please reply to this email or contact our sales department here:
Click Here
if we can assist you by answering further questions or with entering this order and please let us know if there is anything else we can help with.
Q: looking for rod and case assembly for a jackson 1085 door opener
A: The Rod and Case Assembly from the Jackson 1085 is the Jackson 30915J as seen on the 4'th page of the Jackson Parts List here:
Download File
And can be purchased here:
Click Here
Is there a follow up question that we can perhaps attempt to answer? We take deep pride in our technical expertise, as we know it separates us from our competition, so don't hesitate to ask.
Please reply to this email or contact our sales department here:
Click Here
if we can assist you by answering further questions or with entering this order and please let us know if there is anything else we can help with.
Q: Thank you! So, just to confirm, the 8500 electrified trim would be able to latch/unlatch the concealed vertical rod that is already on the door and connected to the 1085 push bar? Thanks!! Drew C
A: That is not entirely correct because the 8500 electrified trim only keeps the lever rigid or unlocked and has no electrical control over the retraction of the last fault whatsoever.
Q: Our Jackson model 1085 does not always close when you exit. To close you must use a key or hit bar really hard. What do we need to do to correct this.
A: Because of this of course could be simple mechanical fatigue on the exit device internal components or a misalignment of the door within the frame itself or the hardware hanging the door. When you state that the device does not always close I wonder if you mean that it doesn't always latch and I would look for some sort of mechanical failure in side of the head case but if it's not closing I might suggest that you review the door closer as well. you'll have to start taking a closer look and determining exactly what base component is causing the breakdown of function - - naturally we can supply you with all of the replacement components for this device once you have determined the cause of operational failure.
Q: What kind of grease should be used on the moving parts of a Jackson 1085?
A: White lithium grease would be my suggestion for the moving parts of a Jackson 1085.
Q: the bottom rod sometimes will not retract. I have to adjust the rod in a higher position often to keep it opening when the panic bar is push in or it will not open at all it will remain in the plate
A: The vertical rod adjustment can be seen on page 16 of the manufacturers product catalog as seen here:
Download File
If you are unable to adjust the rods to a satisfactory level of operation you simply might need to consider replacing the vertical rod assembly all together known as the rod and case assembly which is part number 7 as seen here:
Download File
and can be purchased at the link as seen here:
Click Here
Q: What do I do if I need to install the Jackson 1085 on a 96" tall door?
A: Thank you for the question and if you have 8 ft tall doors you will want to add the part number
CRL 301347 CRL 12" Top Rod Extender for Jackson® Concealed Vertical Rod Panic Exit Device
as seen here:
Click Here
Q: I have a Jackson 1085. The locking pins on the bottom and top want stay up. What would cause that?
A: Very possibly a worn dogging mechanism that needs to be replaced - Rich
