CodeMax® is the Original Computerized Code Machine. Based on the "Standard of the Industry" Blitz™, CodeMax® has an internal computer chip that contains Depth & Space Data (DSD) for more than 900 different lock types. This machine can accommodate keys with up to 14 spaces and 14 depths; it also has a micrometer function in both inch and metric formats. This versatility allows it to cut virtually all standard vehicle, commercial, residential and furniture keys throughout the world. It includes 5 cutters (No. CW-14MC, No. CW-1011, No. CW-47MC, No. CW-90MC and No. CW-20FM)
On the Automatic Angler model, (CodeMax®AA) the cutter pivots automatically to cut high-security angle keys, such as Medeco®, eliminating the need to turn the cutter head manually. Simply enter the depth and direction of the angle, and the CodeMax® AA does the rest. All models of CodeMax® are equipped with a shoulder gauge safety switch. This feature ensures the shoulder gauge is out of the way before you start cutting a key.
The high-performance, long-life motor on CodeMax® provides ample torque for cutting a high volume of keys. It is available in 120VAC or 240VAC for use in locksmith shops around the world.
The total power of CodeMax® is realized when you connect it to your PC. All machines come with a 25-foot (7.5m), 9-pin serial cable for easy connection to your PC. This gives you the ability to download information from MasterKing®, KeyTrail® and CodeSource®. This makes creating new keys as simple as looking up the code on your computer and downloading it to your HPC CodeMax®.
Backed by a 1-year warranty and HPC's Expert Technical Support Department, the CodeMax® is the answer for computerized code cutting!
Additional Information
- Motor: 220/240 VAC 50 cycle
- Shipping Weight: 46 lbs/21kg
- Size: 12"W x 14"D x 14"H
- Bench Size: 20"W x 14"D
Cutters Supplied
- No. CW-14MC Tool Steel, 100° large cylinder
- No. CW-1011 Tool Steel, 90° small cylinder
- No. CW-90MC Tool Steel, 90° large cylinder
- No. CW-20FM Tool Steel, 76° Sargent
- No. CW-47MC Tool Steel, 87° some automotive
Accessories Included
- No. CABLE-25S Cable (for use with software)
- No. CM-1054R Horseshoe Tip Stop
- No. CM-1054MA Red Tip Stop
- No. WRENCH-1 Cutter Adjustment Wrench
- No. WRENCH-2 Space Adjustment Wrench
- No. WRENCH-3 Cutter Nut Wrench
- No. 1200MAX-MAN Manual
|
