Hager 5200 TRK 1-6 ALM NHOTA FC 5902

Name: Hager 5200 TRK 1-6 ALM NHOTA FC 5902 Heavy Duty Surface Door Closer - Non Hold Open Stop Track Arm - Full Cover - for 1-3/4" Doors - Aluminum Finish
Brand: Hager
SKU: Hager 5200 TRK 1-6 ALM NHOTA FC 5902
Price: 270.95 USD

Hager 5200 TRK 1-6 ALM NHOTA FC 5902 Heavy Duty Surface Door Closer - Non Hold Open Stop Track Arm - Full Cover - for 1-3/4" Doors - Aluminum Finish

× This image is for a similar product but it will differ in size, color and/or other attributes.

Hager 5200 TRK 1-6 ALM NHOTA FC 5902 Heavy Duty Surface Door Closer - Non Hold Open Stop Track Arm - Full Cover - for 1-3/4" Doors - Aluminum Finish

Price: $270.95 USD

Comments (Optional)

ADD TO CART

This item is not in stock and typically ships in 15 business days.

+ Add to My Wish List

1-844-809-3667

Sales

sales@absupply.net

Technical Support

tech@absupply.net

Product Description:


Hager 5200 TRK 1-6 ALM NHOTA FC 5902 Heavy Duty Surface Door Closer w/ Non Hold Open Stop Track Arm - Full Cover - for 1-3/4" Doors - Aluminum Finish

Standard Features and Benefits: The heavy duty track arms combined with the proven reliability of the grade 1 closers make for a winning combination. Heavy duty, Grade 1 door closers are ideal for schools, hospitals, and other high-use environments. Specifications: Grade 1 Heavy Duty Surface Door Closer Certifications: BHMA Certified ANSI A156.4, adjustable size 2-5-Standard ADA compliant ANSI A117.1 Accessibility Code only for adjustable sizes 1 to 4 - Optional UL/cUL Listed for up to 3 hours UL10C Positive Pressure Rated UL10B Neutral Pressure Rated Size: 1-6 adjustable. Material: Aluminum Alloy Cover: Full Cover Valve: Adjustable latching and sweep speed valve, adjustable backcheck valve Handing: Non-Handed Arm: Non Hold Open Stop Track Arm Function: Non Hold Open Stop Standard Opening Range: Pull side 120° Hold Open Range: 85° Pocket Applications: 90° pocket door Door Thickness: 1-3/4" (44 mm) - Standard Fasteners: Self-drilling wood & machine screws, sex nuts and bolts for 1-3/4" thick doors, machine screws. Finish: Sprayed Aluminum Content: Standard package contains 5201 closer body, 5202 full plastic cover, non hold open stop track arm, 5204 standard screw pack and 5902 SNB screw pack for 1-3/4" (44 mm) doors Note: Lifetime warranty Full rack and pinion operation 5200 Series Door Closers with Track Arms must be ordered as a complete package	Door Closers General Info 5200 Series Product Brochure Installation Instruction How To Order

Parts:

5201 Closer Body Only 5201 Closer Body
5202 Full Cover 5202 FC Cover
5204 Standard Screw Pack 5204 Standard Screw Pack
5902 SNB Screw Pack Standard 5902 SNB Screw Pack
