Hafele 943.29.011

• Folding wall fitting
• Hawa Variofold 80/H
• Basic Set with Lower Pivot, without Guide Channel
• Load bearing capacity for Panel: (176 lbs.) 80 kg
• Adjustment Height: adjustable ± 3 mm (±1/8")
• For door thickness: up to (1-3/8") 35 mm
• For door width Min: (19-11/16 - 35-7/16") 500 - 900 mm
• Folding/sliding hardware for wall partitions
• For 2 - 7 folding panels
• Upper track made out of anodized aluminum
• Lower guide channel made out of anodized aluminum
• Dual running gear with ball bearings
• Minimal space required in stacking area
• Extremely quiet and smooth operation
• Supplied with:
  • 1 top pivot bearing
  • 1 folding/access door catch, adjustable
  • 1 running gear with support carriage and screw M10
  • 4 support profiles, pre-drilled
  • 1 pressure bearing sleeve, with follower
  • 4 cover caps for support profile
  • 1 height adjustment spanner
  • 1 pressure bearing sleeve, with follower
• Packing & Sold as: Set.
• Note: Unit of measure is Set. When you buy a quantity of 1 you will get one set. Price is for one set.

Required products:

• Upper Track, Pre-drilled: 943.27.960
• Guide Channel, 24 x 24 mm (15/16" x 15/16"): 940.81.600

Optional accessories:

• Doorfix espagnolette lock: 946.21.100
• Heavy Duty Ball Bearing Hinge: 926.21.003
• Door Seal, For Hawa Variofold and Centerfold 80/H: 950.07.423
