Hafele 941.12.000

• Sliding Door Hardware
• EKU Divido 100 GR
• Allows for wood and glass sliding door combinations
• Application: For 1 sliding door without the upper running tracks
• Installation: Single upper running track can be ceiling or wall mounted, Dual upper running track is ceiling mounted
• For door widths greater than 900 mm (35-7/16") it is recommended to use an additional lower guide.
• Load bearing capacity: (220 lbs) 100 kg
• For door height: (9' 1/4") 2750 mm
• For door width: (3' 11-1/4") 1200 mm
• For door thickness: Aluminum frame: (1-3/16") 30 mm
• Adjustment Height: (1/8") +/- 3 mm
• Suitable for: 1 – 4 sliding doors
• Supplied with:
  • 2 x Running gear
  • 2 x suspension nuts and bolts
  • 2 x suspension plate
  • 2 x door stopper
  • 1 x lower guide
  • 1 x set fixing screws
• Packing & Sold as: Set.
• Note: Unit of measure is Set. When you buy a quantity of 1 you will get one set. Price is for one set.

Required products:

• Single Running Track, Pre-Drilled, for Wall Mounting or Ceiling Installation, 39 x 41 mm (W x H): 941.00.253, 941.00.353, 941.00.603
• Dual Running Track, Aluminum, Anodized: 941.12.925, 941.12.935

Optional accessories:

• Spacer Profile, not drilled, for wall mounting the combination track, 11 x 36 mm (W x H): 941.13.220
• Clip-in Skirt, For double running track, pre-drilled, 10 x 42 mm (W x H): 941.12.325, 941.12.335
• Clip-on Fascia, For combination running track, 7 x 60 mm (W x H): 941.12.425, 941.12.435
• Brush Seal, for Clip-On Fascia: 405.80.501
• End Piece, On one side, for wall mounting: 941.12.060
• Soft Closer, For EKU Porta/Divido 60/100: 940.60.010, 940.60.045
• Cover Cap, for Notched Service Access in Track: 940.60.094
• Milling Jig, For notched service access in track: 940.60.095
