Hafele 940.80.015

Name: Hafele 940.80.015 Sliding Door Hardware, Hawa Junior 80/Z, Top Hung System, Without Soft and Self Closing Mechanism, With Track Buffers on Both Sides, For = 80 kg (176 lbs.) Door Weight, Set
Brand: Hafele
SKU: Hafele 940.80.015
Price: 367.33 USD

Hafele 940.80.015 Sliding Door Hardware, Hawa Junior 80/Z, Top Hung System, Without Soft and Self Closing Mechanism, With Track Buffers on Both Sides, For = 80 kg (176 lbs.) Door Weight, Set

× This image is for a similar product but it will differ in size, color and/or other attributes.

Hafele 940.80.015 Sliding Door Hardware, Hawa Junior 80/Z, Top Hung System, Without Soft and Self Closing Mechanism, With Track Buffers on Both Sides, For = 80 kg (176 lbs.) Door Weight, Set

Price: $367.33 USD

Comments (Optional)

ADD TO CART

In Stock (Minimums Apply):

Charlotte, NC Warehouse Qty: 172

For quantities beyond the "In Stock" above, the item(s) ships in 15 business days.

+ Add to My Wish List

1-773-809-3667

Sales

sales@absupply.net

Technical Support

tech@absupply.net

Product Description:

Hafele 940.80.015 Sliding Door Hardware, Hawa Junior 80/Z, Top Hung System, Without Soft and Self Closing Mechanism, With Track Buffers on Both Sides, For = 80 kg (176 lbs.) Door Weight, Set

Sliding door hardware
Model: 80 Z
Version: With track stoppers on both sides
Without soft and self closing mechanism
Area of application: For 1 and 2 sliding wood doors
For door material: Wood
For door weight: = 80 kg (176 lbs.)
For door height: = 4000 mm (157-1/2")
For door width: = 3000 mm (118-1/8")
Note on door width: The max. door width for the pocket door solution is 1500 mm (59").
For door thickness: 35 - 80 mm (1-3/8" - 3-1/6")
Installation: Suspension with screwed on two-way suspension
Installation reference: Installation and removal of the door possible from the door surface or door edge
Number of doors per system max.: 1 to 2
Number of doors: 1
Controller installation options: Ceiling installation, wall mounting, wall pocket solution
Running position: Top
Door processing: For screw fixing
Standard: Certified in compliance with EN 1527:2013
Smooth quiet operation
Outstanding durability
Rattle-free bottom guide
Simple installation
Special two-way suspension
Vertically and laterally adjustable
Door stop with adjustable retention spring
Order reference: Order 2 sets for bi-parting sliding doors.
Additional information:
- No end cap is available for ceiling installation with fascia on both sides.
- A pair of end caps can be attached end to end and glued vertically in the centre of the running track (optional).
Packing & Sold as: Set.
Note: Unit of measure is Set. When you buy a quantity of 1 you will get one set. Price is for one set.

Required products:

Upper Track, Pre-drilled
Running Track, For Wall Mounting, Pre-drilled, For Aluminium or Wooden Panel
Running Track, For Ceiling Installation, Pre-drilled, For Aluminium or Wooden Panel
Guide Rail, 20 x 12 mm (13/16" x 1/2"), Glue-in: 940.41.130
