Hafele 549.60.903

Name: Hafele 549.60.903 Pantry Frame, For Lavido Pantry Pull-Out, (40") 1016 mm Top Shelf Storage, Steel, Silver, Set
Brand: Hafele
SKU: Hafele 549.60.903
Price: 404.25 USD

Hafele 549.60.903 Pantry Frame, For Lavido Pantry Pull-Out, (40") 1016 mm Top Shelf Storage, Steel, Silver, Set

× This image is for a similar product but it will differ in size, color and/or other attributes.

Hafele 549.60.903 Pantry Frame, For Lavido Pantry Pull-Out, (40") 1016 mm Top Shelf Storage, Steel, Silver, Set

Price: $404.25 USD

Comments (Optional)

ADD TO CART

In Stock (Minimums Apply):

Charlotte, NC Warehouse Qty: 14

For quantities beyond the "In Stock" above, the item(s) ships in 15 business days.

+ Add to My Wish List

1-844-809-3667

Sales

sales@absupply.net

Technical Support

tech@absupply.net

Product Description:

Hafele 549.60.903 Pantry Frame, For Lavido Pantry Pull-Out, (40") 1016 mm Top Shelf Storage, Steel, Silver, Set

Pantry Frame
For Lavido Pantry Pull-Out
Top Shelf Storage: (40") 1016 mm
Internal cabinet depth min: (19-11/16") 500 mm
Extension length: (18-1/2") 470 mm
Load bearing capacity: Per shelf (44 lbs) 19.5 kg /Total (286 lbs) 129.5 kg
Application: For use with a hinged door – 165° hinge opening recommended, 90° opening minimum
For 18" to 24" Nominal Cabinet Widths
For Cabinet Width: 500 mm–600 mm
Width dimensions are actual shelf width
Features: Soft open and soft close
Type of pull out: Full extension
Adjustment: Infinite height adjustment feature on shelves – simply lift a lever to unlock the shelf for repositioning
This extremely flexible pantry storage solution provides high visibility and easy-to-reach access from three sides
Tempered glass sides come standard and are removable
Full access to shelves from all 3 sides
Synchronized runner, for perfectly smooth operation
Material: Steel
Finish: Silver
Order reference: There are 3 components you need to order for the Lavido Pantry: Pantry Frame, Trays, Full Extension Runner
Packing & Sold as: Set.
Note: Unit of measure is Set. When you buy a quantity of 1 you will get one set. Price is for one set.

LAVIDO Pantry Pull-Out:

This extremely flexible pantry storage solution provides high visibility and easy-to-reach access from three sides
Synchronized, full extension pantry runner
Infinite height adjustment feature on shelves; simply lift a lever to unlock the shelf for repositioning
For use with a hinged door–165º hinge opening recommended, 90º opening minimum
For 450–600 mm (18"–24") nominal cabinet widths
Minimum inside cabinet depth: 500 mm (19-11/16")
Weight capacity: 20 kg (44 lbs.) per shelf / 130 kg (286 lbs.) total
Pull-out travel: 470 mm (18-1/2")

Required products:

Tray Set (of Four), for LAVIDO Pantry Pull-Out: 549.60.254, 549.60.255, 549.60.256, 549.64.204, 549.64.205, 549.64.206, 549.64.214, 549.64.215, 549.64.216, 549.64.224, 549.64.225, 549.64.226
Full Extension Runner, for LAVIDO Pantry Pull-Out: 549.60.990

Optional accessories:

Individual Adjustable Tray, for LAVIDO Pantry Pull-Out: 549.60.254, 549.60.255, 549.60.256
Optional E-Touch Auto Opener, for LAVIDO Pantry Pull-Out: 549.60.599
