DOR-O-MATIC 2090 EO

Name: DOR-O-MATIC Rim Crossbar Device 2090 EO
Brand: Dor-O-Matic
SKU: DOR-O-MATIC 2090 EO
Price: 359.38 USD

DOR-O-MATIC Rim Crossbar Device 2090 EO

× This image is for a similar product but it will differ in size, color and/or other attributes.

Video Review DOR-O-MATIC Rim Crossbar Device 2090 EO

Price: $359.38 USD

Comments (Optional)

ADD TO CART

This item is not in stock and typically ships in 1 business day.

Additional Declarations - This manufacturer has an order minimum of $85.00 - if your total is less than this amount, the lead time approximately 2-3 weeks before it would ship. Simply exceed this minimum order amount so that we can drop ship the material to your location.

+ Add to My Wish List

1-773-809-3667

Sales

sales@absupply.net

Technical Support

tech@absupply.net

Product Description:

Dor-O-Matic Concealed Vertical Rod Device 2090 EO

Classic Looks In A Rim Exit Device. The 2090’s balanced appearance, dependable performance, and economical pricing has made it a popular choice where rim exit devices are required.

Product Features

Equipped with a 1/2˝ throw steel latchbolt

Can be mounted on stiles as narrow as 1 3/4˝

Removable mullions are available for pairs of doors applications

Surface mounted strikes for full frame or blade type stops

U.L. Listed 305

Field adjustable width

Grade 1

Exit Only

Order Options Guide

Color Options

P28 689 Painted Aluminum – Silver

P13 695 Painted Aluminum – Dark Bronze

Handing

Please be sure to select the correct hand when ordering. For instance you may notice the Right Hand and Left Hand Reverse drawings look similar. Indeed they appear to be similar. But there is a very important difference between them. The Right Hand drawing shows the push side of the door to be the locked (usually exterior) side of the door. But the Left Hand Reverse drawing shows the locked side of the door to be the pull side. This difference is significant when talking about door hardware as the application of that hardware is dependant upon the swing of a door.
Handing Chart


Customer Supplied Photo (Click to Enlarge)

Video Review of DOR-O-MATIC Rim Crossbar Device 2090 EO

Video Detail Page

Questions and Answers

Q: Is the old Doromatic 1090 the same as a 2090?

A: Yes, with the exceptions that the 2090 base material is aluminum whereas the 1090 was either brass or bronze base material depending on the finish.

Q: I am looking for a video or how to instructions for replacing the Dor-o-matic 2090 Lever Arm. This is the interior hinge for the right hand side of the panic bar that has the cylinder and pull on the exterior. We are a small school with a tiny budget and I can not call in a locksmith if this is something that I can replace. Thanks for any directions. I found a video online that your company posted so I thought I would ask for advice.

A: A short video of the DOR-O-MATIC Rim Crossbar Device 2090 EO Lever Arm Replacement procedure is detailed here:

Click Here

The referenced documents are here:

Dor-o-matic 2090 Parts Diagram Dor-o-matic 2013 version:

Download File

And the Dor-o-matic 2090 Parts Diagram Falcon 2019 version:

Download File

Q: What is the part # for Doromatic pinion cam?

A: The Part numbers are:

4270903177 for 1 each as seen here:

Click Here

CAM.102 for a package of 10 as seen here:
