Bilco PCM-8 Type PCM - Single Leaf - Floor Access Precast Vault Door - 30" x 60" - 300 PSF
×
This image is for a similar product but it will differ in size, color and/or other attributes.
×
This product review video is for a similar product but it will differ in size, color and/or other attributes.
Price:
$
3,852.88 USD
In Stock Ready for Shipment
Comments
(Optional)
ADD TO CART
This item is not in stock and typically ships in 15-20 business days.
Check Inventory
Request Quote
No Minimum
There is no minimum quantity required for this product for quantities up to the level listed below.
Minimum Order Levels Apply
This item has minimum order levels that need to be met.
Check Inventory Levels
Enter your email address and we will check with all available sources and get back to you with exact inventory levels and estimated shipping times.
Qty. Needed:
Request Quote
Enter the qty needed and we will generate a quote and save your order in our system.
You will not be charged and we will not fulfill the order.
Qty. Needed:
+ Add to My Wish List
1-844-809-3667
Sales
sales@absupply.net
Technical Support
tech@absupply.net
Product Description:
Type PCM - Single Leaf - Floor Access Precast Vault Door - 30" x 60" - 300 PSF
Standard Features and Benefits:
Type PCM single leaf access doors incorporate several innovative features which reduce the amount of labor required to cast the door into a concrete vault.
To simplify installion on a standard concrete vault form, doors are designed with a 6" (152mm) high frame (other frame depths abvailable) and have no vertical projections below the frame.
Doors are constructed of aluminum and feature a peel off covering to protect the door's finish during the pouring process.
Automatic hold-open arm and cover release
Torsion/Cam operating mechanism.
Door shall be 1/4" aluminum 6061-T6 diamond pattern plate to withstand a live load od 300 pounds per square foot. The frame shall be 1/4" extruded aluminum 6063-T5 channel shaped to provide a drainage gutter and an overall depth of 6" for a 6" concrete slab thickness.
A 1-1/2" pipe coupling shall be provided on the exterior vertical leg of the frame at the front right corner. Door shall be equipped with heavy forged brass hinges with stainless steel pins and fasteners. A type 316 stainless steel snap lock with removable handle shall be provided.
A stainless steel torsion bar mechanism, acting through cams, shall provide ease of operation through the entire arc of opening and for safety act as a check in retarding downward motion of the door.
A heavy steel automatic hold open arm shall include a red vinyl grip for handy release. Arm shall be zinc plated and chromate sealed.
Specifications:
Size:
30"W x 60"L.
Cover:
Diamond-pattern tread plate reinforced for 300 psf (1464 kg/m2) live load. Peel off protective covering.
Frame:
1/4" Aluminum Channel Frame for 6" slab thickness. Bituminous coating on exterior of frame.
Hinges:
Heavy forged brass hinges with 3/8" (9 mm) type 316 stainless steel hinge pins.
Locking and Latching Devices:
Standard is a flush spring loaded snap lock operable from the outside by a removable handle and from bellow by fixed turn handle. Locking and latching options are: a recessed padlock hasp covered by a hinged lid flush with surface, a cylinder lock with keyway protected by a threaded cover plug, lugs welded to the exterior door surface to receive a padlock, a hinged padlock hasp on the exterior door surface.
Finish:
Aluminum shall be mill finish with bituminous coating applied to the exterior of the frame.
Brochure
Template
Installation Instructions
Questions and Answers
Q: I’m inquiring about the Bilco PCM-8 Type PCM - Single Leaf - Floor Access Precast Vault Door - 30" x 60" - 300 PSF I was looking for a recessed style to conceal with carpet and it only needs to be light pedestrian rated. I’m refitting it into an existing concrete floor. I would like to be hinged on the short side. Please advise. Thank you,
A:
The Bilco PCM-8 Type PCM - Single Leaf - Floor Access Precast Vault Door - 30" x 60" - 300 PSF cannot be hinged on the 30" side.
