Bilco NB-20VM VersaMount Replacement Hatch - Type NB Ship Stair Access - 30" x 54" - Galvanized Steel Cover And Curb
×
This image is for a similar product but it will differ in size, color and/or other attributes.
×
This product review video is for a similar product but it will differ in size, color and/or other attributes.
Price:
$
2,041.78 USD
In Stock Ready for Shipment
Comments
(Optional)
ADD TO CART
This item is not in stock and typically ships in 10-15 business days.
Check Inventory
Request Quote
No Minimum
There is no minimum quantity required for this product for quantities up to the level listed below.
Minimum Order Levels Apply
This item has minimum order levels that need to be met.
Check Inventory Levels
Enter your email address and we will check with all available sources and get back to you with exact inventory levels and estimated shipping times.
Qty. Needed:
Request Quote
Enter the qty needed and we will generate a quote and save your order in our system.
You will not be charged and we will not fulfill the order.
Qty. Needed:
+ Add to My Wish List
1-844-809-3667
Sales
sales@absupply.net
Technical Support
tech@absupply.net
Product Description:
VersaMount Replacement Hatch - Type NB Ship Stair Access - 30" x 54" - Galvanized Steel Cover And Curb
Standard Features and Benefits:
The VersaMount replacement hatch allows you to replace a damaged roof hatch without re-roofing. Simply remove the cover from the damaged hatch and place the Versamount hatch on top of the existing curb. The low-profile VersaMount curb features a built-in flange and apron and innovative anchor clip system to ensure a fast, secure, and weathertight installation
Built-in apron simplifies installation on existing curbs and ensures watertightness
Engineered with compression spring operators to provide smooth, easy, one-hand operation, regardless of size
Automatic hold-open arm locks the cover in the open position to ensure safe egress
Overlapping cover design, full welded corners on cover and curb, EPDM rubber gasket, and fully insulated cover and curb ensure weather tightness and energy efficiency
Constructed with corrosion resistant materials to provide many years of trouble free, dependable service
Heavy gauge construction and positive latching mechanism maintain building security
Available in many sizes and curb configurations to satisfy any requirement or installation
Guide Specifications:
Material:
Steel- Cover and frame are 14 gauge (2 mm) G-90 paint bond galvanized steel.
Cover:
Brake formed, hollow-metal design with 1" (25 mm) concealed fiberglass insulation, 3" (76 mm) beaded, overlapping flange, fully welded at corners, and internally reinforced for 40 psf (195 kg/m2) live load.
Curb:
4" (102mm) in height, breakformed hollow-metal design with 1" (25 mm) concealed fiberglass insulation, 2-5/8" (67 mm) mounting flange and 1-1/2" (38 mm) apron, fully welded at corners. Stainless steel anchor clips are included.
Gasket:
Extruded EPDM rubber gasket permanently adhered to cover.
Hinges:
Heavy-duty pintle hinges with 3/8" (9 mm) Type 316 stainless steel hinge pins.
Latch:
Slam latch with interior and exterior turn handles and padlock hasps.
Lift Assistance:
Compression spring operators enclosed in telescopic tubes. Automatic hold-open arm with grip handle release.
Finish:
Alkyd base red oxide primer.
Hardware:
Engineered composite compression spring tubes with steel compression springs packed in grease. All other hardware is zinc plated/chromate sealed
Brochure
Installation Instruction
Cut Sheet
Template
