Q: my key cutter are cutting the keys wrong its out of adjustment please help
A: The Service Manual for the
Best Access AD433-2 Key Combinator
Can be reviewed at the link here
:
Click Here
If additional service is needed after having reviewed the manual please reach back out to us and we will contact the factory to request a review of what a service repair might cost to bring your unit back to original operating condition.
Q: I am looking at ordering a AD433 Best Combinator. I see AD433-2 and -3, etc... How do I know which one to order?
A: How you order this is using either -2 for A2, -3 for A3 and -4 for A4 system.
The difference on the A2, A3 and A4 is the pin stack height as summarized here:
A2: 23
A3: 16
A4: 14
and also
Difference between pin lengths:
A2: 0.0125"
A3: 0.018"
A4: 0.021"
Most systems will be A2 with a few being A4...
Q: I had someone chat requesting which of the Best Access AD433s have the ability to cut a Q keyway... Do you know the answer to this or should I consult with the manufacturer..? Thanks!--
A: There would be no restriction with cutting a 'Q' keyway from Best with the Best Access AD433 Key Combinator.
we simply need to specify the correct configuration of the machine based on the system deployed at the time of order.
Q: Thanks for the quick response. I have a couple more questions for you. Looks like this combinator will cut all keyways for standard best keys. From what I'm reading on the manual nothing needs to be adjusted going back and forth between keyways correct? Assuming the combinator is new, correct? Do you guys sell Q keyway blanks? If so how much for large orders (aprox 500 keys). We are a commercial property management company and have several best key schedules that we manage. Looking to take key duplication in house. Thanks!
A: I would argue, not to dissuade you from this key purchase, this task can be accomplished for FAR less money based on your potential purchase. How many keys do you cut a month?
Q: Richard I seen you video on the best right hand key cuter as seen here:
Click Here
You said that you sell to the government. I am a Locksmith on Fort Hood Texas in Killeen Texas . I was wondering if you sell to us because we get a lot of our lock parts for intermountain Security supply ? If you don’t let me know so maybe we can buy from you. They are sometimes looking for new suppliers. Thanks Ray
A: We will certainly sell to you and I very often sell these combinators to military installations as Best keying systems are most prevalent on military installations - what specifically may I do to assist at this time?
Q: I am trying to find out how to convert my AD433-2 so I can cut the BEST KABA Peaks keys. Do I need a new machine or can they be converted?
A: The Best AS433 series of combinator's are very fine pieces of equipment and I do understand what you would like to do. I will happily review your ability to convert your machine - please tell me now do you have a left hand or right hand configured combinator? Also let me know are you looking to cut 6 pin or 7 pin Peaks keyblanks.
Q: Thank you for getting back to me. I have a right hand unit I currently use for my A2 cores and we will be doing 7 pin Peaks blanks
A: According to the Best service manual,
All patented keyways require a LH configuration, therefore, your right-hand combinator cannot be converted to cut Peaks 7 - pin for your A2 system. The tool that you need is the Best Access AD437 Key Combinator as seen here:
Click Here
A Parts Drawing can ve reviewed here:
Download File
Q: I have a left hand machine currently cutting with "p" carriage can it be switched to use a standard A2 carriage?
A: Unfortunately no as “
All standard keyways require a RH configuration for the key combinator.” according to the combinating equipment service manual as seen on page 2 - 4 of the link as seen here:
Download File
Q: I have a 433-2 left hand drive with the "p" carriage What keyway is that used for the base plate says B1? is that Kaba peaks B1??
A: The AD433 cuts only Standard keys. The AS436 & AD437 will cut Peaks B1 & B2 keyways. The Peaks models will always be Left Hand configuration.
Please see the document as link to here for further information:
Download File
Q: I need a replacement pawl for the AD433-2
A: The pawl assembly would not be available as a separate stand-alone product for the
Best Access AD433-2 Key Combinator.
Having said that we can indeed offer you factory service where the machine would be ultimately sent to the manufacturer for review & inspection. If you would like to investigate this as an option please feel free to reach out to our sales department as seen here:
Click Here
I have posted a link as seen here:
Download File
Best Access Key Combinators should that be of any help to you.
Q: I need a new handle for our unit. Where can I get parts?
A: The part that you need is the Best Access A70595 Operating Lever Assembly as seen here:
Click Here
And can also be seen on page 2-2 of the manufacturer service manual as seen here:
Download File
Q: does the AD433P cut standard keys?
A: Great question. The Best AD433-2 Key Combinator, according to the Best service manual on page 2-4 as seen here:
Download File
Standard keys are cut by the AD433 key combinator.
Q: On the AD433-2 (using a WC keyway) what is the client doing incorrectly as they cannot get the key to enter the carriage completely?
A: The WC is a premium keyway and requires a premium cutter to accommodate the thicker key = Ad433P as seen here:
Click Here
You could replace the carriage C70579 = premium key carriage as seen here:
Click Here
Q: We are converting from an A2 6 pin system to an A2 7 pin COREMAX system. How do I change our AD433-2 from 6 cuts to 7 cuts?
A: What keyway Coremax are you converting to?
Q: Will the AD433P-A2 also cut standard blanks in addition to WC premium blanks?
A: No. The AD433P-A2 will not accurately cut standard keys. The WC keyway requires the AD433P-2 RH as seen here:
Click Here
Q: What combinator is needed to originate Coremax keys?
A: AD433 + key system. Example for an A2 = AD433-2 This will cut Cormax and standard best key ways,
Q: The client is in an A2 environment. The client needs to originate a patented B7 key. Are they to use the AD436-2 combinator?
A: For Peaks there are 2 options which are
AD436-2 as seen here:
Click Here
or AD437-2 as seen here:
Click Here
depending on if they are cutting for 6 or 7 pin
