ASI A0247-TRBS

copy to clipboard

ASI A0247-TRBS TRI-Umph™ Wall Protector Absorptive Backsplash with Mounting Frame

enlarge
enlarge
× This image is for a similar product but it will differ in size, color and/or other attributes.
ASI A0247-TRBS TRI-Umph™ Wall Protector Absorptive Backsplash with Mounting Frame
More from ASI
Price: $79.19 USD
Ships From
Comments (Optional)
ADD TO CART
In Stock (Minimums Apply):
Yonkers, NY Warehouse Qty: 1
For quantities beyond the "In Stock" above, the item(s) ships in 4 business days with $82.50 minimum purchase of ASI products or 15 business days for smaller orders.

ASI has a minimum order requirement. Orders smaller than the required minimum have a longer lead time as we need to consolidate onto a "stock" order. If you need a faster lead time, simply exceed the minimum order amount.

+ Add to My Wish List

1-773-809-3667

Sales
sales@absupply.net
Technical Support
tech@absupply.net
Product Description:
ASI A0247-TRBS TRI-Umph™ Wall Protector Absorptive Backsplash with Mounting Frame
  • Made of proprietary absorptive-evaporative ceramic that matches the composition of the water droplet evaporator plate on the TRI-Umph™ hand dryer and has a black powder coated 20 gage steel frame suitable for surface mounting with eight (8) screws (by others).
  • The absorptive-evaporative plate is 9/32" (7.4 mm) thick and has a face finish of medium matte gray to match the TRI-Umph™ hand dryer.
  • Frame is formed from one piece of steel and has no exposed seams or welded joints and has four (4) exposed mounting tabs formed from frame edges.
  • Frame holds the plate on all edges and only the gray face is visible inside the black frame.
  • Overall Size: 10-7/16" W x 8-7/8" H x 3/8" D (265 x 226 x 9 mm)
    		•

Specifications
  • Wall Protector Backsplash Plate with Mounting Frame shall be proprietary absorptive-evaporative ceramic matching composition of water droplet evaporator plate on ASI Model № 20200 TRI-Umph™ hand dryer and shall have a black powder coated 20 gage steel frame suitable for surface mounting with eight (8) screws (by others).
  • Absorptive-evaporative plate shall be 9/32" (7.4) thick and have face finish of medium matte gray to match ASI Model № 20200 TRI-Umph™ hand dryer.
  • Frame shall be formed from one piece of steel and have no exposed seams or welded joints and shall have four (4) exposed mounting tabs formed from frame edges.
  • Frame shall hold plate on all edges and only the gray face shall be visible inside the black frame.
Operation
  • Plate absorbs water droplets that may blast past the absorptive-evaporative ceramic evaporator plate on ASI Model № 20200 TRI-Umph™ hand dryer.
  • Plate continuously evaporates water at a rate matching the absorption of castoff droplets from hand dryer usage.
  • Water cast-off droplets absorbed and subsequently evaporated from plate are prevented from soaking into wall finish behind.
  • Plate may be cleaned at the same time as the dryer unit following instructions found in the dryer Owner Manual.
Installation
  • Mount unit on wall surface using eight (8) № 8 self-tapping screws (by others) through exposed 3/16" diameter (Ø4.8) mounting holes into appropriately prepared anchors (by others).
  • Center the unit directly behind the hand chamber of ASI Model № 20200 TRI-Umph™ hand dryer.
