Cover shall have shoulder pin at top to interlock back plate V-notch when closed and shall be held closed by a tumbler lock keyed to other ASI washroom equipment with key provided. Mounting bracket shall have five (5) mounting holes to suit № 10 flat head screws (by others). A viewing slot with clear plastic window shall continuously indicate supply level. Unit shall accommodate smaller core size roll by removing the rubber core adapter O-rings. Opening on bottom of cabinet shall have stainless steel teeth on both sides for tearing toilet paper. All exposed surfaces shall be satin finish and shall be protected during shipment with heavy gauge clear plastic bag to be removed before unit installation.
One (1) 13-1/2" (Ø343) max OD jumbo roll of toilet paper with core ID of 2-1/4"(Ø57) or larger and 4-5/16" (110) face width may be hung on fixed spindle when cover is opened. Alternatively one (1) 1-5/8" ID (Ø41.3) core roll may be used by removing the rubber core adapter rings. Viewing slot continuously reveals tissue level. Key locked cover prevents unauthorized access or removal. Roll is replaced on a cycle determined by maintenance needs.
