Product Description:

ASI Surface Mounted Paper Towel Dispenser

Holds 800 standard multi-fold or 600 standard C-fold paper towel
Satin stainless steel
Tumbler lock keyed alike to other ASI products
Rough wall opening is 12-3/4" W x 26-1/2" H x 4" D minimum (324mm x 673mm x 102mm)

Cut Sheet

Operation

Towels are self-feeding until supply is depleted.
Unit may be reloaded with a partial load in-place and will continue to feed properly.

Installation

Rough Wall Opening (RWO) required is 12-3/4" W x 26-1/2" H x 4" D minimum (324mm x 673mm x 102mm)
Unit is recessed mounted in wall using No10 screws (by others) through concealed mounting holes provided.
For compliance with ADA Accessibility Guidelines, unit should be installed so that towel dispenser slot is 54" (1372mm) maximum above finished floor (AFF) if clear floor side reach access is provided or 48" (1219mm) maximum AFF if clear floor forward reach access only is provided.
To comply with CalDAG mounting height, towel dispenser slot should be 40" (1016mm) AFF.
Note that bottom of RWO is 3/4" (19mm) above bottom of unit.
