Q: do you know if anyone makes a router template for installing these?
A: No one makes a template specifically for the Adams Rite MS1847 - having said this - you could certainly use the Porter Cable 517 Heavy-Duty Lock Mortiser Template as seen here:
Click Here
and here:
Download File
Adjust the unit so as to be set to the proper width and height for your lock prep.
However the issue there is to account for the
17/32" body width but the 1/4" radius on the -06 or -09 variants of the lock body. Please note the Stile Preparation on page two of the Cut Sheet seen here:
Download File
Clearly states a 17/32" wide prep.
We do sell a 17/32" diameter router bit as seen herr:
Click Here
and given the fact your prep at the radiused ends will be only .032" larger than needed - you might not concern yourself (alternately you could use a 1/2" bit to get the perfect top x bottom radiuses and the retool and do the 17/32" for the flat sides and stopping short of when the radius occurs).
Is there a follow up question that we can perhaps attempt to answer? We take deep pride in our technical expertise, as we know it separates us from our competition, so don't hesitate to ask.
Please reply to this email or contact our sales department here:
Click Here
if we can assist you by answering further questions or with entering this order and please let us know if there is anything else we can help with. If this answer was helpful -
please consider following us on Twitter
Click Here
or liking our page on Facebook
Click Here
Q: Rich, We spoke on the phone earlier this week about the ms1847, which I have ordered from your website since. I picked 2 day air, so hopefully you've already sent it. On Yelp I left you a more positive review, which I'll update after our transaction(s).
Also, we spoke about a jig, so I'd like to thank you again for your help. I thought you'd appreciate this other jig I found. It's here: Trend Lock Jig. I haven't bought it yet, so I'm not sure if the templates the provide will be exactly what I'll need for this deadlatch, but I'm sure I can have my families shop laser cut me the perfect template that'll slip right into this. It's magnetic, so it's literally a snap. I'll let you know how I like it, but so far the reviews & videos I've seen are very promising. Next, I'll be trying out different tools and techniques for cutting the aluminum, but I believe it cuts similar to wood, with carbide tools. Thanks again for the help! Respectfully, Bob W
A: Yes indeed we have already sent the order and the tracking number has been provided to you via email.
Thank you for the review and I look forward to your report on your installation process using this "Trend" installation tool. I am unfamiliar with it altogether and hope you can take lots of photos and even videos of your work and progress and forward them to me.
Is there a follow up question that we can perhaps attempt to answer? We take deep pride in our technical expertise (something Amazon can not provide) as we know it separates us from our competition, so don't hesitate to ask.
