Model: BCD-JG926AABA
Description:
The HP 1920 Switch Series, part of the HP OfficeConnect portfolio, is designed for smaller organizations dealing with bandwidth-demanding applications. The switches are ideal for environments that require advanced features for granular control and where smart-managed flexibility is a must for easy network configuration and management. The switches deliver advanced smart-managed fixed configuration Gigabit switches that build on the marketing-leading price/performance of the HP 1910 Switch Series. They feature a new 48-port PoE+ model, IPv6 support and advanced silicon technology.
Features:
- Capacity:
- Type: IPv4 routing table entries
- Value: 32
- Dimensions & Weight:
- Depth: 10.2 in
- Height: 1.7 in
- Weight: 7.5 lbs
- Width: 17.3 in
- Environmental Parameters:
- Humidity Range Operating: 10 - 90% (non-condensing)
- Humidity Range Storage: 10 - 95% (non-condensing)
- Max Operating Temperature: 104 °F
- Max Storage Temperature: 158 °F
- Min Operating Temperature: 32 °F
- Min Storage Temperature: -40 °F
- Flash Memory:
- Header:
- Brand: HPE
- Compatibility: PC
- Manufacturer: ProCurve Networking
- Model: 1920-24G-PoE+
- Packaged Quantity: 1
- Product Line: HPE
- Interface Provided:
- Comments: PoE+
- Connector Type: RJ-45
- Qty: 24
- Type: 1000Base-T
- Connector Type: SFP
- Qty: 4
- Type: 1000Base-X
- Comments: Management
- Qty: 1
- Type: Console
- Miscellaneous:
- Authentication Method: RADIUS , Secure Shell (SSH)
- Color Category: Gray
- Compliant Standards: CAN/CSA C22.2 No. 60950-1-03 , CISPR 22 Class A , EN 60950-1 , EN 61000-3-2:2000 , EN 61000-3-3 , EN55022 Class A , EN55024 , FCC Part 15 A , ICES-003 Class A , IEC 60950-1 , RoHS , UL 60950 , VCCI Class A , WEEE
- Encryption Algorithm: SSL
- Height (Rack Units): 1
- MTBF: 65.78 year(s)
- Rack Mounting Kit: Included
- Networking:
- Advanced Switching: Layer 3
- Compliant Standards: IEEE 802.1ab (LLDP) , IEEE 802.1D , IEEE 802.1p , IEEE 802.1Q , IEEE 802.1s , IEEE 802.1w , IEEE 802.1x , IEEE 802.3 , IEEE 802.3ab , IEEE 802.3ad (LACP) , IEEE 802.3af , IEEE 802.3at , IEEE 802.3az , IEEE 802.3i , IEEE 802.3u , IEEE 802.3x , IEEE 802.3z
- Connectivity Technology: Wired
- Features: Access Control List (ACL) support , ARP support , Auto-negotiation , Auto-uplink (auto MDI/MDI-X) , Cable Diagnostics Function , Class of Service (CoS) , DHCP client , DHCP relay , Dual firmware images , Flow control , IGMP snooping , IPv6 support , Jumbo Frames support , Layer 2 switching , MLD snooping , Multiple Spanning Tree Protocol (MSTP) support , Port isolation , Port mirroring , Port Security , Quality of Service (QoS) , Rapid Spanning Tree Protocol (RSTP) support , Single IP Management (SIM) , Spanning Tree Protocol (STP) support , Static routing , STP Root Guard , Strict Priority Queuing (SPQ) , Syslog support , VLAN support , Weighted Round Robin (WRR) queuing
- Form Factor: Desktop , Rack-mountable
- Jumbo Frame Support: 10KB
- MAC Address Table Size: 8192 entries
- Manageable: Yes
- PoE Budget: 370 W
- Ports Qty: 24
- Power Over Ethernet (PoE): PoE+
- Remote Management Protocol: CLI , HTTP , HTTPS , RMON 2 , SNMP 1 , SNMP 2c , SNMP 3 , Telnet , TFTP
- Routing Protocol: Static IPv4 routing , Static IPv6 routing
- Subcategory: Network hubs and switches
- Subtype: Gigabit Ethernet
- Type: Switch
- Performance:
- Type: Throughput
- Value: 41.7 Mpps
- Type: Routing/switching capacity
- Value: 56 Gbps
- Ports:
- Qty: 24
- Type: 10/100/1000 (PoE+)
- Ports (2nd):
- Power Device:
- Frequency Required: 50/60 Hz
- Nominal Voltage: AC 120/230 V
- Power Consumption Operational: 474 Watt
- Processor:
- Clock Speed: 500 MHz
- Installed Qty: 1
- Manufacturer: MIPS
- RAM
- Installed Size: 128 MB
- Technology: SDRAM
|
