Features
- Model: ADCI600FB521
- Operational:
- Video Compression: H.264/MJPEG
- Max Frame Rate: 720p @ 30ips
- ONVIF-Compliant: Yes
- Resolutions: 720p (1280x720), SVGA (800x600), D1 (720x480), VGA (640x480), CIF (352x240)
- Imager: 1/3" CMOS
- Day/Night: Mechanical ICR
- Minimum Illumination: 0.5 lux at F1.5 color, 0.00 lux in IR Illuminator Mode
- IR Illuminator: Effective Distance is 25m/82ft, IR Wavelength 850mn
- Shutter Speed: 1/7.5~1/8000 sec
- Backlight Compensation: Off/On (6 Selectable Areas)
- Lens Focal Length: 9-22mm F1.5 Varifocal Lens
- Field of View (H/V): Wide Angle - 30.6°/22.6°, Telephoto -13°/9.8°
- White Balance: ATW (2500K~8000K)/Manual
- Alarms: Motion Detection
- Alarm Input: 1
- Audio Input: 1
- Audio Format: G.711-Alaw/G.711-Ulaw
- Video Output: 1
- Video Stream: Triple
- Wide Dynamic Range: Digital WDR
- Digital Noise Reduction: 3D
- Privacy Zones: Yes, 4
- Menu Languages: Arabic, Chinese (Simplified), Chinese (Traditional), Czech, Dutch, English (default), French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish
- Network:
- Ethernet: RJ-45 Connector
- Supported Protocols: IPv4, HTTP, HTTPS, TCP, RTSP/RTCP/RTP, ICMP, UDP, IGMP, DNS, DHCP, ARP, NTP, SMTP
- Configuration Management:
- Web Browsing Requirements: Internet Explorer 8.0 or Above
- Security: Multiple User Access Levels with Password Protection
- Electrical:
- Power: 24V AC, PoE 802.3af Class 0
- Power Consumption: 15W max. (with LED & Heater on Using 24V AC)
- Physical:
- Dimension: Ø 4.53" x 10.39" (Ø 115 mm x 264 mm)
- Weight: 2.3 kg (5.07 lbs)
- Housing Material: Main Body - AI 6063-T5, Rear Case/Brackets - ADC12
- Housing Color: Silver Pantone 877C
- Operating Temperature: 24V AC Power: -40°C to 50°C (-40°F to 122°F), PoE Power - -10°C to 50°C (14°F to 122°F)
- Operating Humidity: . 0% to 90%, Non-condensing
- Storage Temperature: -20°C to 60°C (-4°F to 140°F)
|
