- Features:
- Model: ACI-Q111
- Product Type: Fisheye Covert
- Maximum Resolution: 5MP
- Application Environment: Indoor
- Image Sensor: Progressive Scan CMOS(Complementary Metal-Oxide Semiconductor)
- Day/Night: No
- Low Light Sensitivity: Standard
- Sensor Size: 1/3.2 "
- Effective Pixels: 2592(H) X 1944(V) (5.04 MP)
- Minimum Illumination: Color: 0.1 lux at F 2.0 (30 IRE, 2400 K)
- Mechanical IR Cut Filter: No
- IR LED: No
- Focal Length: Fixed Focal, f1.19mm
- Aperture: F2.0
- Maximum Frame Rate vs. Resolution: 15 fps at 2592 x 1944, 15 fps at 2048 x 1536, 15 fps at 1440 x 1080, 15 fps at 1280 x 960, 15 fps at 800 x 600, 15 fps at 640 x 480, 15 fps at 320 x 240
- Horizontal Resolution (TV Lines): 1350 TVL
- Horizontal Viewing Angle: 189.67° (Overview Area), 115.7° (High Detail Area)
- Compression: H.264 (Baseline/ Main/ High Profile), MJPEG
- Power Source: DC 12V, PoE Class 2 (IEEE802.3af)
- Power Consumption: 4.32 W (PoE)
- Signal to Noise Ratio: 52 dB
- Wide Dynamic Range: Basic WDR (74 dB)
- Digital Noise Reduction: 2D + 3D DNR
- Iris: Fixed Iris
- Focus: Fixed Focus
- Lens Mount: RJ12 Connector Up To 12m From Main Unit
- View Mode: Fisheye View
- Multi-Streaming: Simultaneous Dual Streams
- Privacy Mask: 4 Configurable Regions
- VMS-based Analytics: Face Detection, Object Based Motion Detection, Tamper, People Counting, Line Crossing, Enter Area, Exit Area, Appear in Area, Missing Object, Unattended Object, Crowd Detection, Direction Detection, Vehicle Counting, Heat Map, License Plate Recognition, Speed Estimation, (Require PC-based or Standalone IVS or ALPR Server)
- Audio Type: 2-way, Mic-in, Line-in, Line-out
- Network Protocol & Service: TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
- Ethernet Port: 1 x RJ-45 Connector
- Serial Port: 1 x RS-232
- Digital Input/Output: 1/1
- Local Storage: MicroSDHC, MicroSDXC Memory Card Slot (Card Not Included)
- Environmental Casing: Vibration Proof (EN50155)
- Mount Type: Flush, Tiltable Flush Mount
- Starting Temperature: -20 °C ~ 50 °C (-4 °F ~ 122 °F)
- Operating Temperature: -30 °C ~ 60 °C (-22 °F ~ 140 °F)
- Approvals: CE, FCC, EN50155, UL (For Optional PoE Injector and Power Adapter)
- GPS Position: Manual Setting
- ONVIF Compliant: Yes, Profile S, Profile G, (To Be Available Through Future Firmware Upgrade)
- Web Browser: IE 8.0 or Newer, Firefox with VLC, Chrome with VLC, Safari with QuickTime
- Warranty: 3 Years
- Extended Warranty: 2 Years
|
