- Features:
- Model: ACI-E32
- Product Type: Bullet
- Maximum Resolution: 3MP
- Application Environment: Outdoor
- Image Sensor: Progressive Scan CMOS (Complementary Metal-Oxide Semiconductor)
- Day/Night: Yes
- Low Light Sensitivity: Standard
- Sensor Size: 1/3.2 "
- Effective Pixels: 2592(H) X 1944(V) (5.04 MP)
- Minimum Illumination: Color: 0.1 lux at F 1.8 (30 IRE, 2400 K); B/W: 0 lux at F 1.8 (IR LED on)
- Mechanical IR Cut Filter: Yes
- IR LED: Adaptive IR LED x 20 (850 nm)
- IR Working Distance: 30m (0 lux, 30IRE, Gain 255, Auto Shutter Mode)
- Horizontal Resolution (TV Lines): 1350 TVL
- Focal Length: Fixed focal, f4.2mm
- Maximum Frame Rate vs. Resolution: 15 fps at 2048 x 1536, 30 fps at 1920 x 1080, 30 fps at 1280 x 720, 30 fps at 800 x 600, 30 fps at 640 x 480, 15 fps at 320 x 240
- Horizontal Viewing Angle: 62.7°
- Aperture: F1.8
- Signal to Noise Ratio: 52 dB
- Wide Dynamic Range: Basic WDR (74 dB)
- Iris: Fixed Iris
- Focus: Fixed Focus
- Lens Mount: Board Mount
- Compression: H.264 (Baseline/ Main/ High Profile), MJPEG
- Multi-Streaming: Simultaneous Dual Streams Based on Two Configurations
- Image Enhancement: White Balance, Brightness, Contrast, Sharpness, Automatic Gain Control, Flickerless
- Digital Noise Reduction: DNR
- Privacy Mask: 4 Configurable Regions
- VMS-based Analytics: Face Detection, Object Based Motion Detection, Tamper, People Counting, Line Crossing, Enter Area, Exit Area, Appear in Area, Missing Object, Unattended Object, Crowd Detection, Direction Detection, Vehicle Counting, Heat Map, License Plate Recognition, Speed Estimation, (Require PC-based or Standalone IVS or ALPR Server)
- Image Orientation: Flip, Mirror
- Network Protocol & Service: TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
- Ethernet Port: 1, Ethernet (10/100 Base-T), RJ-45 Connector
- Local Storage: No
- Power Source: PoE Class 2 (IEEE802.3af)
- Power Consumption: 4.85 W (PoE)
- Environmental Casing: Weatherproof (IP68), Vandal Proof Petal Casing (IK10)
- Bundled Accessories: Bracket
- Mount Type: Corner Mount, Pole Mount, Bracket
- Starting Temperature: -20 °C ~ 50 °C (-4 °F ~ 122 °F)
- Operating Temperature: -40 °C ~ 50 °C (-40 °F ~ 122 °F)
- Approvals:CE (EN 55022 Class B, EN 55024), FCC (Part15 Subpart B Class B), IP68, IK10 (metal casing), UL (for optional PoE injector)
- Software Development Kit (SDK): Yes
- GPS Position: Manual setting
- ONVIF Compliant: Yes, Profile S
- Web Browser: IE 8.0 or Newer, Chrome with VLC, Firefox with VLC, Safari with QuickTime
- Warranty: 3 Years
- Extended Warranty: 2 Years
|
