 — Unidirectional K band sensor.
For dedicated ADA-use doors only.
Adjustable elliptical sensing pattern.
Adjustments include unidirectional, unidirectional with motion tracking feature, bidirectional sensing capability, wide or narrow patterns, 3-dimensional angle adjustment, and heightened immunity to highly sensitive motion settings.
Adjustments via PS-1 RMT remote control.
Self-monitored ready out of the box, used with or without a self-monitored ready system.
Includes 0°–90° vertical and –30°– +30° lateral tilt angle, powered by 12–24 VAC±10% or 12–24 VDC .
Designed for use in openings designated specifically for barrier-free accessibility.
Should not be used in combination with ED800 in openings used for pedestrian traffic or where high-speed operation/ opening is needed.
Precise setup of the motion sensor detection area is necessary so nearby traffic is not picked up. |
