Yale 781N

Name: Yale 781N Controller (782N is new part#)
Brand: Yale
SKU: Yale 781N
Price: 830.38 USD

Yale 781N Controller (782N is new part#)

× This image is for a similar product but it will differ in size, color and/or other attributes.

Yale 781N Controller (782N is new part#)

Video Review Yale 781N Controller (782N is new part#)

Price: $830.38 USD

Comments (Optional)

ADD TO CART

In Stock (Minimums Apply):

For quantities beyond the "In Stock" above, the item(s) ships in 1 business day.

Additional Declarations - This manufacturer has an order minimum of $85.00 - if your total is less than this amount, the lead time approximately 2-3 weeks before it would ship. Simply exceed this minimum order amount so that we can drop ship the material to your location.

+ Add to My Wish List

1-844-809-3667

Sales

[email protected]

Technical Support

[email protected]

Product Description:

Yale 781N Controller for the 7000 Series Electrified Exit Devices

Installation Instructions Yale 1998 version

Installation Instructions ASSA/ABLOY 2014 version

Templates

Product Brochure

OPERATION

Designed to control one or two electric latch retraction “P” exit devices. Equipped with two 20-second timers which can operate the exit devices together or independently. Requires a momentary or timed, dry contact input and can be interfaced with access control systems, automatic door operators, “blow open” type scenarios and has provisions for N/C fire alarm systems.
Note: The 781N is required for use with the “P” latch retraction option. Using any other power supply with the “P” option voids the warranty of the device.

ELECTRICAL SPECIFICATIONS

	• 120VAC or 120VAC 60 Hz Power input
	• 9 amp inrush for 100 milliseconds

FEATURES

	• 2 control inputs. Accepts normally closed dry contacts for device activation from a key switch, push button, access control or fire alarm system.
	• 2 normally open control outputs for automatic door operators
	• 2 “P” device outputs
	• Fire Alarm Interface input
	• 12VDC output for audible or LEDS .25 AMP
	• 24VDC output for audible or LEDS .25 AMP
