While this pivots specifications, when reviewed, indicated Door Sizes up to 4'0" x 8'6" , I have sold this pivot dozens of times where client has used it on 5/0 wide and wider doors. It is my belief the weight rating of the pivot of 1,000 lbs is what allows the hardware to handle applications outside of the hardwares designed performance envelope.
The issue of a door closer becomes more complicated because I do not have experience where there are successful installations of floor closers on 5/0 wide doors. Everything in the Rixson book seen here:
Download File
limits us to 4/0 wide and a failure of the unit would not allow us any recourse with the factory.
My opinion is H28 seen on page 21 in the above link would likely handle to job, but I am not in a position to give you anything more concrete than my opinion.
Anything for 3" thick doors would be factory order which is typically 4 - weeks.
Please let us know if there is anything else we can help with.
