Markar HG326001630

Markar HG326001630 300 Series Continuous Hinge, 7 Feet, Half Surface, Stainless Steel, Pin And Barrel

× This image is for a similar product but it will differ in size, color and/or other attributes.

Markar HG326001630 300 Series Continuous Hinge, 7 Feet, Half Surface, Stainless Steel, Pin And Barrel

+ Add to My Wish List

Quote Only Item

This item must be quoted prior to order. Please Contact Us for further details.

1-844-809-3667

Sales

sales@absupply.net

Technical Support

tech@absupply.net

Product Description:

Markar HG326001630 300 Series Continuous Hinge, 7 Feet, Half Surface, Stainless Steel, Pin And Barrel

The integral hinge guard protects the door from dings and gouges from carts and gurneys while providing clean lines and aesthetic appearance. Our HG products also have fire ratings up to and including 3 hours.

Continous Hinge 83.125" long
3/16" diameter stainless steel barrel type hinge pin
Medical bearings
Stainless steel end pins
Heavy-duty 14 gauge, stainless steel, finished in US32D
Fasteners concealed when door is closed
Fastener screw pack includes Custom 12-24 x 11/16 S.S Phillips Flat Head Undercut TEK Screws.
Supports weights up to 600lbs. 4'0" maximum door width
Symmetrically templated hole pattern
Specify handing for 6'8", 7'2" and for most optional features
Exterior barrel diameter .438 (7/16)
Optional features include US32 Bright Polished Stainless, custom lengths (specify handing and length in inches), custom hole patterns, tamper-proof security screws.
ANSI/BHMA Standard A156.26 Grade 1
Finish: Satin Stainless Steel
Type: Hinges and Pivots
Sub Type: Continuous Hinge
Security Lock UID: MAR100HG326001630
Packing & Sold as: Each.
Note: Unit of measure is EA. When you buy a quantity of 1 you will get one piece. Price is for one piece.
