2'0 x 7'0 Particleboard Core Red Oak Wood Door
|
| |
|
|
PSRO-PC2070 |
2'0 x 7'0 Particleboard Core Red Oak Wood Door
|
| |
| Manufacturer: ABS |
| Price: $126.89
|
|
| |
| |
|
| |
| |
| |
|
|
|
This product review video is for a similar product but it will differ in size, color and/or other attribute. We still feel the video will be of value to you.
|
|
 |
|
 |
|
| |
|
Availability: IN STOCK. Ready to ship. |
Our PARTICLE BOARD CORE DOORS, AWI specification FPC-9, are for standard residential use or economy commercial applications. The standard features of this door are one piece stiles (not finger jointed), particle board core and can be rated for up 20 minute. There doors carry our one year warranty for interior applications. Since not every application calls for an architectural solid core door, this economy door is a dependable alternative. This door is well suited for commercial tenant build-out or commercial retail jobs where cost is a primary concern along with quality. These doors are available 1 3/4" or 1 3/8" thick. Additionally special sizes are also available. Please contact our sales office directly for your custom size door needs
|
| CONSTRUCTION |
Floating particle core |
| CORE |
particleboard which complies with ANSI A208.1 1-LD2 or 1-LD1 |
THICKNESS |
1 3/4", 1 3/8" |
| STILES |
1-1/4" min. (before trim) Structural Composite Lumber (SCL) with compatible veneer band or decoraive laminate |
| RAILS |
2-1/4" min. (before trim) mill option hardwood or SCL |
| CROSSBANDS |
1/12" select hardwood with grain running 90° to face veneer |
| FACES |
Wood veneer |
| ADHESIVE |
Type II Venners
Type I Door assembly |
| FIRE RATING |
20 minute - 1 3/4" thick doors only |
| DOOR DETAILS |
Lite and louver openings not to exceed 54" in length or 40% of the door. Max 1296" for 20 min label |
| MAXIMUM SIZES |
Singles: 3/0, 8/0
Double: 6/0, 8/0
|
|
|
|
|
Contact Information |
|
877-631-9411
Contact Architectural Builders Supply for installation support and information ! |
 |
TOP and BOTTOM HORIZONTAL EDGE |
| 2 1/4" minimum solid wood or structural composite lumber, one piece or laminated (before trim) |
| VERTICAL EDGE |
| 1 9/16" minimum hardwood; solid, laminated or veneered (before trim). Backer or inner ply may be structural composite lumber. Same species visible surface, sanded ease, no visible joints allowed |
|
|
| CORE |
| Particleboard, ANSI A208.1, 1-LD2 or 1-LD1 |
| CORE/EDGE INTERFACE |
| Stiles & rails securely bonded to core, then entire unit abrasively planed before veneering |
| |
| CROSSBAND |
| Edge glued or one piece without voidsor show through |
| VENEER FACE |
| Rotary Natural Birch and Plain Sliced Red Oak |
| VENEER MATCH |
| Book, slip or random; Centered, balanced or running; Pair and set match |
| LIGHTS, LOUVERS and MOULDING |
| Metal vision frames open for 1/4" wired glass or 3/16" Firelite NT glass. Max visible glass 1296 sq in; max width36", mx length 54". Wood lip, wood flush or Metal Vision Panel |
| TRANSOMS |
| Available |
| FIELD TRIM |
| Width = Max. 1/2" when taken equally from both stiles |
| Height = Max. 1" when taken equally from both rails |
|
Cutting Graphic |
Cutting Explained |
|
|
 |
ROTARY CUT
The log is mounted centrally in the lathe and turned against a razor sharp blade, like unwinding a roll of paper. Since this cut follows the log's annual growth ring, a bold variegated grain marking is produced. Rotary cut veneer is exceptionally wide. To put it simply, this is the way you peel an apple |
|
|
|
PLAIN SLICING
The log, or flitch, is mounted with the heart side flat against the flitch table of the slicer and the slicing is done parallel to a line through the center of the log. This produces a variegated figure. To put it simply this is the way meat is sliced at the deli |
|
|
QUATER SLICING
The quarter log, or flitch, is mounted on the flitch table so that the growth rings of the log strike the knife at approximately right angles, producing a series of stripes, straight in some wood, varied on others |
|
|
RIFT CUT
Cut veneer is produced in the various species of Oak. Oak has medullary ray cells which radiate from the center of the log like curved spokes of a wheel. The rift or comb grain effect is obtained by cutting at an angle of 15 degree of the quarter |
ABS STANDARD |
| GRADE DESCRIPTION |
"A" |
| COLOR MATCHING |
|
| Sapwood |
5% |
| Heartwood |
Yes |
| Color Streaks or Spots |
Yes |
| Color Variation |
Slight |
| Sharp Color Contrasts at Joints |
No |
| TYPES OF MATCHING |
|
| Book Matched |
Yes |
| Slip Matched |
Specify |
| Pleasing Matched |
N/A |
| Random Matched |
Specify |
| End Matched |
Specify |
| Nominal Minimum width of Face Components |
Plain Sliced = 5"
Quartered = 3"
Rotary = 5"
|
NATURAL CHARACTERISTICS |
| Small Conspicuos Burls & Pin Knots Combined AVG Number |
1 per 22/3 SQ.FT.MAX
12 in and 32 SQ FT. CONTIGUOUS |
| Conspicuous Burls Max Size |
3/8" |
| Conspicuous Pin Knots AVG Number |
1 per 3 SQ. FT. MAX 10 IN AND 32 SQ. FT CONTIGUOUS |
| Max. Pin Knot Size - Dark Part |
1/8" |
| Scattered Sound and Repaired Knots - Combined Avg. Number |
No |
| Max. Size - Sound |
No |
| Max. Size - Repaired |
No |
| Avg. Number - Repaired |
No |
| Mineral Streaks |
Slight |
| Bark Pockets |
No |
| Worm Tracks |
No |
| Vine Marks |
Slight |
| Cross Bars |
Slight |
|
|
Unfilled worm holes, open splits, open joints, open bark pockets, shake or doze not permitted in above grades |
10% sap allowed in Rift and Plain Sliced; 20% sap allowed in Rotary |
In the absence of specific flitch selection by owners representative, the natural |
Distribution of ray fleck in Quarter cut Red Oak is permitted |
All data referenced from A.W.I. 7'th edition, version 1.0 1997, section 1300 |
|
