2'0 x 6'8 Architectural Lumber Core Birch Wood Door RNB-LC2068
|
| |
|
|
RNB-LC2068 |
2'0 x 6'8 Architectural Lumber Core Birch Wood Door RNB-LC2068
|
| |
| Manufacturer: ABS |
| Price: $290.86
|
|
| |
| |
|
| |
| |
| |
|
|
|
This product review video is for a similar product but it will differ in size, color and/or other attribute. We still feel the video will be of value to you.
|
|
 |
|
 |
|
| |
|
Availability: IN STOCK. Ready to ship. |
Architectural Lumber Core doors are build to withstand the most abusive applications. These doors feature solid 2" top & bottom rails and most commonly used in schools, hospitals and goverment building. Our lumber core doors are manufactured with a network of solid blocks of lumber laminated together with a very strong adhesive to form a single, solid, stable door core reducing the risk of core telegraphing or warp. This door type offers superior stability and screwholding power when compared to particle core doors and is approved for use by the Architectural Woodwork Institute (AWI) and the Windows & manufacturers Association (WDMA). |
STRUCTURAL COMPOSITE LUMBER CORE SLC |
| CONSTRUCTION |
Bonded 5 Ply Hot Press |
| CORE |
Solid Lumber Wood Staves |
THICKNESS |
1 3/4", 1 3/8 Door available on special order |
| STILES |
7/8" Matching hardwood or softwood. Wider stiles available |
| RAILS |
N/A |
| CROSSBANDS |
1/12" select hardwood with grain running 90° to face veneer |
| FACES |
Wood veneer, plastic laminate and MDO (optional) |
| ADHESIVE |
Type II (water resistant)
Type I (water-proof) available |
| FIRE RATING |
20 Minute - 1 3/4" thick doors only |
| DOOR DETAILS |
Full Lite Door : 5" Top Rail, 5" Stiles and 8" Bottom Rail. 1 1/4 required between lite opening and lock cut-out.
20 Min Label Door: 5 1/2" Top Rail, 5 1/2" between door edge and lock cut-out and 8" bottom rail. Max 1296" for 20 min label. |
| MAXIMUM SIZES |
Singles: 4-0 x 10-0; Pairs: 8-0 x 10-0; DE Pairs: 8-0 x 8-0 |
 |
TOP and BOTTOM HORIZONTAL EDGE |
| 2 1/4" minimum solid wood or structural composite lumber, one piece or laminated (before trim) |
| VERTICAL EDGE |
| 1 9/16" minimum hardwood; solid, laminated or veneered (before trim) |
| Backer or inner ply may be structural composite lumber. |
| Same species visible surface, sanded ease, no visble joints allowed |
| CORE |
| Staved Lumber Core |
| CORE/EDGE INTERFACE |
| Stiles & rails securely bonded to core, then entire unit abrasively planed before veneering |
| BACK VENEER |
| CROSSBAND |
| Edge glued or one piece without voids or show through |
| VENEER FACE |
| Minimum 1/50" "A" grade egde glued joints. 1/8" hardboard 60 lb. ANSI A 135.4 |
| VENEER MATCH |
| Book, slip or random; Centered, balanced or running; Pair and set match |
| LIGHTS, LOUVERS and MOULDING |
| Same species lumber, or vennered or metal vision frames |
| TRANSOMS |
| Bottom horizontal edge runs full width. Matching species lumber or vennered |
| FIELD TRIM |
| Width = Max. 1/2" when taken equally from both stiles |
| Height = Max. 1 1.2" when taken equally from both rails |
| |
Maximum Door Size |
Assembly |
Blocking Options |
| Unrated |
Width |
Height |
Bonded:
Frame componets are bonded to the core. Componets are assemled to meet or exceed 20 minute fire door specifications. Assembly is then uniformly sanded on both faces prior to vennering to prevent telegraphing. |
Stiles |
N/A |
| Single Leaf |
4'0" |
10'0" |
Rails |
| Single w/ Transom |
4'0" |
10'0" |
Lock Block |
| Transom |
4'0" |
3'0" |
Closer Block |
| Pair |
8'0" |
10'0" |
Panic Block |
| Dbl Egress Pair |
8'0" |
10'0" |
Standard Custom sized as specified |
| Dutch Door |
4'0" |
8'0" |
Blockings mill option lumber |
| FD-20 |
Quality Standards
Premium Grade per AW section 1300 and WDMA #S-17 Type SLC-5 and FCLC 20-7 bonded core with matching stiles |
Available Species:
All commercially available |
| Single Leaf |
4'0" |
10'0" |
| Single w/ Transom |
4'0" |
10'0" |
| Transom |
4'0" |
3'0" |
| Pair |
8'0" |
10'0" |
| Dbl Egress Pair |
8'0" |
10'0" |
| Dutch Door |
4'0" |
8'0" |
| Thickness Options |
Warranty
Interior - Lifetime (original installation only).
Exterior -2 -year |
Finishing |
| 1 3/8" unrated |
Priming |
| 1 3/4" unrated of FD-20 |
Finish painting |
| 2 1/4" unrated |
Clear coating |
| Other thickness unrated |
Standard color staining |
| |
Custom color staining |
Cutting Graphic |
Cutting Explained |
|
|
 |
ROTARY CUT
The log is mounted centrally in the lathe and turned against a razor sharp blade, like unwinding a roll of paper. Since this cut follows the log's annual growth ring, a bold variegated grain marking is produced. Rotary cut veneer is exceptionally wide. To put it simply, this is the way you peel an apple |
|
|
|
PLAIN SLICING
The log, or flitch, is mounted with the heart side flat against the flitch table of the slicer and the slicing is done parallel to a line through the center of the log. This produces a variegated figure. To put it simply this is the way meat is sliced at the deli |
|
|
QUATER SLICING
The quarter log, or flitch, is mounted on the flitch table so that the growth rings of the log strike the knife at approximately right angles, producing a series of stripes, straight in some wood, varied ion others |
|
|
RIFT CUT
Cut veneer is produced in the various species of Oak. Oak has medullary ray cells which radiate from the center of the log like curved spokes of a wheel. The rift or comb grain effect is obtained by cutting at an angle of 15 degree of the quarter |
ABS STANDARD |
| GRADE DESCRIPTION |
"A" |
| COLOR AND MATCHING |
|
| Sapwood |
Yes |
| Heartwood |
Yes |
| Color Streaks or Spots |
Yes |
| Color Variation |
Yes |
| Sharp Color Contrasts at Joints |
No |
| TYPES OF MATCHING |
|
| Book Matched |
Yes |
| Slip Matched |
Specify |
| Pleasing Matched |
N/A |
| Random Matched |
Specify |
| End Matched |
Specify |
| Nominal Minimum width of Face Components |
Plain Sliced = 5"
Quartered = 3"
Rotary = 5"
|
NATURAL CHARACTERISTICS |
| Small Conspicuos Burls & Pin Knots Combined AVG Number |
1 per 3 sq. ft. max. 10 in and 32 sq. ft. contiguous |
| Conspicuous Burls Max Size |
3/8" |
| Conspicuous Pin Knots AVG Number |
1 per 8 sq. ft. max. 4 in and 32 sq. ft. contiguous |
| Max. Pin Knot Size - Dark Part |
1/8" |
| Max, Pin Knot Size - Total |
1/4" |
| Scattered Sound and Repaired Knots - Combined Avg. Number |
No |
| Max. Size - Sound |
No |
| Max. Size - Repaired |
No |
| Avg. Number - Repaired |
No |
| Mineral Streaks |
Slight |
| Bark Pockets |
No |
| Worm Tracks |
No |
| Vine Marks |
Slight |
| Cross Bars |
Slight |
MANUFACTURING CHARACTERISTICS |
| Rough Cut |
No |
| Blended Repaired Tapered Hairline Splits |
Two 1/16"x 6" |
| Repairs |
Small Blending |
|
SPECIAL CHARACTERISTICS |
UNFILLED WORM HOLES, OPEN SPLITS, OPEN JOINTS, OPEN BARK POCKETS, SHAKE OR DOZE NOT PERMITTED IN ABOVE GRADES |
ALL DATA REFERENCED FROM A.W.I. 7 TH EDITION, VERSION 1.0.1997 SECTION 1300 |
|
